What is the Sitrak Battery Box (Flush Mounted)

  • The Sitrak Battery Box (Flush Mounted) is an essential component designed to securely house the vehicle’s battery, ensuring optimal performance and protection. This battery box is a well – engineered system composed of multiple key elements that work together seamlessly.
  • The Battery box assembly forms the core of the structure. It is meticulously designed to fit the battery snugly and provide a stable environment. The assembly is built to withstand various environmental conditions and vibrations during the vehicle’s operation.
  • Reinforced angle assemblies play a crucial role in enhancing the strength of the battery box. These assemblies are strategically placed to provide additional support and prevent any deformation or damage to the box. Two such Reinforced angle assemblies are incorporated into the design, ensuring maximum structural integrity.
  • Screws are used to fasten different parts of the battery box together. They provide a reliable connection, keeping all components in place and maintaining the overall stability of the box.
  • The Lower rubber gasket is another important part. It acts as a seal, preventing water, dust, and other contaminants from entering the battery box. This helps to protect the battery from corrosion and other potential damage, thereby extending its lifespan.
  • A Protection strip is added to the battery box. It serves as a buffer, protecting the box from scratches and impacts. This strip not only enhances the durability of the box but also gives it a more polished look.
  • Fixing clips are used to secure various components within the battery box. They ensure that everything stays in its proper position, even under rough driving conditions.
  • The Hexagonal flange face nut M8 is employed in the fastening process. Its hexagonal shape makes it easy to tighten with standard tools, and the flange face provides a larger contact area, distributing the clamping force evenly.
  • The New battery box cover assembly is designed to fit flush with the rest of the vehicle, giving it a sleek and integrated appearance. It also provides an additional layer of protection for the battery.
  • A Large washer is used in combination with the nuts and screws. It helps to distribute the load and prevent the fasteners from loosening over time, ensuring a long – lasting and secure installation.
  • In summary, the Sitrak Battery Box (Flush Mounted) with its comprehensive set of components including the battery box assembly, reinforced angle assemblies, screws, rubber gasket, protection strip, fixing clips, hexagonal flange face nut M8, new battery box cover assembly, and large washer, offers a reliable and durable solution for housing the vehicle’s battery. It is a testament to Sitrak’s commitment to quality and innovation in vehicle components.

Product Parameters of Sitrak Battery Box (Flush Mounted)

711-#0460-0338  Battery Box (Flush Mounted)
No. Part Number Part Name English  Quantity
1 811W41860-5385 Battery box assembly 1
2 811W41860-5368 Reinforced angle assembly 1
3 811W41860-5369 Reinforced angle assembly 1
4 811W95101-0142 Screw 4
5 AZ9100760108 Lower rubber gasket 1
6 WG9725360073 Protection strip 2
7 811W41860-0148 Fixing clip 2
8 ZQ32008T13F6 Hexagonal flange face nut M8 12
9 811W41860-6094 New battery box cover assembly 1
10 Q40208 Large washer 4
