What is the Sitrak 600l Pedal + 400l Aluminum Fuel Tank(675x620 Section/Heated Suction And Return Oil)(600l Fuel Tank Heating/Cold Zone Package)

  • Sitrak 600l Pedal + 400l Aluminum Fuel Tank(675×620 Section/Heated Suction And Return Oil)(600l Fuel Tank Heating/Cold Zone Package)

  • The Sitrak 600l Pedal + 400l Aluminum Fuel Tank system is a remarkable innovation designed specifically for vehicles operating in cold – zone conditions. With its 675×620 section and heated suction and return oil, along with a 600l fuel tank heating/cold zone package, it ensures reliable fuel supply and efficient operation in frigid environments.
  • On the right side, there is a 600L Aluminum Pedal Fuel Tank (675X620) equipped with a fuel heating function. This fuel heating feature is crucial as it maintains the fuel at an optimal temperature, preventing it from thickening or solidifying in cold weather. This ensures that the engine receives a consistent and proper fuel supply, enhancing the vehicle’s overall performance and reliability.

  • Sitrak 600l Pedal + 400l Aluminum Fuel Tank(675×620 Section/Heated Suction And Return Oil)(600l Fuel Tank Heating/Cold Zone Package)

  • The 400L Aluminum Fuel Tank (675×620) is left – mounted, providing additional fuel storage capacity. Together, the 600L and 400L tanks offer a substantial fuel reserve, allowing vehicles to cover long distances without frequent refueling, which is especially beneficial for long – haul operations in cold regions.
  • Accurate fuel level monitoring is made possible by two types of oil level sensors. The Fuel Level Sensor (675×620 Fuel Tank/Quick Plug/Water Heating) features a quick – plug design for easy installation. The water – heating function ensures accurate readings even in extremely cold conditions, as it prevents the sensor from being affected by low temperatures. The Oil level sensor (675×620 tank/quick plug type/with heater return port) not only has a quick – plug mechanism but also includes a heater return port, which helps in maintaining proper fuel circulation and temperature control within the tank.
  • The connection and sealing components are essential for the proper functioning of the fuel and heating systems. Pipe connectors play a vital role in the oil transfer process. The Pipe connector (to 16X2 oil pipe/straight) and the Pipe connector (for 16X2 fuel pipe/straight) are designed to provide a direct and unobstructed path for the oil and fuel, minimizing pressure losses and ensuring efficient delivery.

  • Sitrak 600l Pedal + 400l Aluminum Fuel Tank(675×620 Section/Heated Suction And Return Oil)(600l Fuel Tank Heating/Cold Zone Package)

  • Fittings are used to secure connections. The Fitting (M16x1.5/Long) is suitable for connections that require extra length, while the Connector (M16x1.5/short) can be used in tight – space installations. The Composite sealing washer 16 QZZ21052 is used at all connection points. Made from high – quality composite materials, it provides a tight and leak – free seal, protecting the system from fuel and water leakage.
  • The water management system is an integral part of the tank’s heating mechanism. The water hose from the water shut – off valve (ball valve to fuel tank/φ16 – φ12 reducer/T7 – 1 version/B version) is responsible for transferring water from the ball valve to the fuel tank. The Ball valve assembly offers precise control over the water flow, enabling users to easily regulate the water supply for the heating system.

  • Sitrak 600l Pedal + 400l Aluminum Fuel Tank(675×620 Section/Heated Suction And Return Oil)(600l Fuel Tank Heating/Cold Zone Package)

  • There are multiple water hoses in the package. Tee components are used to split or combine water flows, enhancing the flexibility of the water circulation within the heating system. To secure the water hoses firmly, Hose clamps are provided. These clamps prevent any potential leaks and ensure a reliable water supply for the heating process.
  • In summary, the Sitrak 600l Pedal + 400l Aluminum Fuel Tank system combines large – capacity fuel storage, efficient fuel heating, and reliable monitoring and connection components, making it a top – choice for cold – zone vehicle applications.

Product Parameters of Sitrak 600l Pedal + 400l Aluminum Fuel Tank(675x620 Section/Heated Suction And Return Oil)(600l Fuel Tank Heating/Cold Zone Package)

711-#0230-0218  600l Pedal + 400l Aluminum Fuel Tank(675×620 Section/Heated Suction And Return Oil)(600l Fuel Tank Heating/Cold Zone Package)
No. Part Number Part Name English  Quantity
1 WG9925556708 600L Aluminum Pedal Fuel Tank(675X620)-Right Side(Fuel Heating) 1
2 WG9925550709 Fuel Level Sensor(675×620 Fuel Tank/Quick Plug/Water Heating) 1
3 190003989302 Hose clamps 8
4 WG9715111017 Water hose from water shut-off valve (ball valve to fuel tank/φ16-φ12 reducer/T7-1 version/B version) 1
5 WG9715110050 Ball valve assembly 1
6 WG9725550206 Pipe connector (to 16X2 oil pipe/straight) 2
6 WG9725550206 Pipe connector (for 16X2 fuel pipe/straight) 2
7 WG9725550165 Fitting(M16x1.5/Long) 1
8 AZ9003090016 Composite sealing washer 16 QZZ21052 2
9 WG9925550714 Oil level sensor(675×620 tank/quick plug type/with heater return port) 1
10 WG9725550166 Connector(M16x1.5/short) 1
11 WG9925555003 400L Aluminum Fuel Tank(675×620)_left mounted 1
12 WG9925551727 Water hose 1
13 WG9925551726 Water hose 1
14 WG9925533108 Tee 1
