Sitrak 600+560l Aluminum Tank (675x620 Section/Heated Suction And Return Oil)
Sitrak 600+560l Aluminum Tank (675×620 Section/Heated Suction And Return Oil)
2025-03-29
Sitrak 600l(440l+160l) Right-Mounted Double-Chamber Aluminum Alloy Fuel Tank(675x620 Section/Heated Suction And Return Oil)(Tank Heating/Cold Zone Package)
Sitrak 600l(440l+160l) Right-Mounted Double-Chamber Aluminum Alloy Fuel Tank(675×620 Section/Heated Suction And Return Oil)(Tank Heating/Cold Zone Package)
2025-03-29

Sitrak 400l(300l+100l) Around Universal Double-Chamber Aluminum Alloy Fuel Tank(675x620 Section/Heating Suction And Return Oil)(Tank Heating/Cold Zone Package)

Sitrak 400l(300l+100l) Around Universal Double-Chamber Aluminum Alloy Fuel Tank(675x620 Section/Heating Suction And Return Oil)(Tank Heating/Cold Zone Package)
Sitrak 400l(300l+100l) Around Universal Double-Chamber Aluminum Alloy Fuel Tank(675x620 Section/Heating Suction And Return Oil)(Tank Heating/Cold Zone Package)
Download Catalog
Get Quotation

What is the Sitrak 400l(300l+100l) Around Universal Double-Chamber Aluminum Alloy Fuel Tank(675x620 Section/Heating Suction And Return Oil)(Tank Heating/Cold Zone Package)

  • The Sitrak 400l (300l + 100l) Around Universal Double – Chamber Aluminum Alloy Fuel Tank, with a 675×620 section and featuring heating suction and return oil capabilities along with a tank heating/cold zone package, is a revolutionary solution for fuel storage in demanding environments.
  • At the core of this fuel tank system is the 400L (300L + 100L) Aluminum Fuel Tank (675×620) located on the left side, equipped with fuel heating functionality. This double – chamber design offers flexibility in fuel management and ensures a consistent supply of heated fuel, which is crucial in cold zones.
  • The system is complemented by a range of essential components. The ball valve assembly plays a vital role in controlling the flow of fluids within the tank, providing precise shut – off capabilities when needed.
  • There are water hoses that are an integral part of the system. The water hose from the water shut – off valve comes in different configurations, such as the ball valve to tank setup with a φ16 – φ12 reducer, available in both T7 – 1 version and B version. These hoses are designed to transfer water efficiently, which is often used in the heating process of the fuel. Hose clamps are used to secure these hoses, preventing any potential leaks and ensuring a tight fit.
  • The oil level sensors are key features of this fuel tank. There is an oil level sensor (675×620 tank/quick plug type/water heating). This sensor allows for quick and easy installation and provides accurate readings of the oil level while also being integrated with the water heating system. Another oil level sensor (675×620 tank/quick – insertion type/with heater pickup and return port) offers real – time monitoring of the oil level and is directly connected to the heater’s pickup and return ports, enabling efficient fuel heating.
  • Pipe connectors and fittings are essential for the proper functioning of the fuel lines. The pipe connector for the 16X2 oil pipe, which is straight, ensures a smooth and direct flow of fuel. The straight fitting for the 16X2 fuel line also contributes to efficient fuel transfer. There are both long and short fittings with the specification of M16x1.5. The long fittings are suitable for connections that require more length, while the short fittings are perfect for tight – space installations.
  • Composite sealing washers 16 QZZ21052 are used to ensure a tight and leak – free seal at various connection points. These washers are made from high – quality composite materials, providing excellent resistance to fuel and other chemicals.
  • Lastly, water hoses and a tee are included in the system. The tee is used to split or combine fluid flows, enhancing the flexibility of the water circulation within the heating system. Overall, the Sitrak 400l (300l + 100l) Around Universal Double – Chamber Aluminum Alloy Fuel Tank is a comprehensive and reliable solution for vehicles operating in challenging conditions.

Product Parameters of Sitrak 400l(300l+100l) Around Universal Double-Chamber Aluminum Alloy Fuel Tank(675x620 Section/Heating Suction And Return Oil)(Tank Heating/Cold Zone Package)

711-#0230-0212  400l(300l+100l) Around Universal Double-Chamber Aluminum Alloy Fuel Tank(675×620 Section/Heating Suction And Return Oil)(Tank Heating/Cold Zone Package)
No. Part Number Part Name English  Quantity
1 WG9715110050 Ball valve assembly 1
2 WG9715111017 Water hose from water shut-off valve (ball valve to tank/φ16-φ12 reducer/T7-1 version/B version) 1
3 190003989302 Hose clamp 8
4 WG9925550709 Oil level sensor (675×620 tank/quick plug type/water heating) 1
5 WG9725550206 Pipe connector (for 16X2 oil pipe/straight) 2
5 WG9725550206 Fitting(16X2 fuel line/straight) 2
6 WG9725550165 Fitting(M16x1.5/Long) 1
7 WG9725550166 Fitting(M16x1.5/short) 1
8 AZ9003090016 Composite sealing washer 16 QZZ21052 2
9 WG9925550714 Oil level sensor(675×620 tank/quick-insertion type/with heater pickup and return port) 1
10 WG9925555033 400L(300L+100L)Aluminum Fuel Tank(675×620)_Left (Fuel Heating) 1
11 WG9925551726 Water Hose 1
12 WG9925551727 Water hose 1
13 WG9925533108 Tee 1
WG9925555033 400L(300L+100L)Aluminum Fuel Tank(675X620)_Left Side(Fuel Heating)
No. Part Number Part Name English  Quantity
1 WG9925555033/1 400L(300L+100L) Aluminum Fuel Tank(675X620)_Left Side(Fuel Heating)(Rubber Factory) 1
WG9925555033/1 400L(300L+100L) Aluminum Fuel Tank(675X620)_Left Mount(Fuel Heating)(Rubber Factory)
No. Part Number Part Name English  Quantity
1 AZ9003090018 Composite Sealing Washer 18 QZZ21052 2
2 WG9112556005/1 Strainer(Rubber Factory) 2
3 WG9925555013/1 Drain port bolt plug (with wedge groove)(Rubber factory) 2
