Shacman X6000 Side Marker Lights (Fuel Tank)
Download Catalog
Get Quotation

What is the Shacman X6000 Side Marker Lights (Fuel Tank)？

  • Shacman X6000 Side Marker Lights (Fuel Tank): Reliable Signaling for Commercial Vehicle Safety​
  • Engineered to deliver consistent visibility and corrosion resistance in fuel tank environments, the Shacman X6000 Side Marker Lights (Fuel Tank) integrate high-performance LED technology, robust mounting hardware, and fuel-resistant materials—LED Side Marker Lamp with Reflector, Side Marker Lamp Mounting Bracket, and precision fasteners—to ensure optimal conspicuity, structural integrity, and compatibility with fuel tank installations. Designed for the X6000 series, this lighting solution balances advanced optics with heavy-duty durability, ideal for logistics, construction, and long-haul fleets operating in harsh conditions.​
  • Core Lighting Component: High-Efficiency LED Module​
  • The LED Side Marker Lamp with Reflector features a 5W high-intensity LED (luminous flux: 250 lm, color temperature: 6,000K) encased in a polycarbonate lens (thickness: 3mm) with a parabolic reflector (reflectivity ≥ 92%), projecting light up to 200m for enhanced side visibility. Compliant with UN ECE R87 photometric standards, the module emits a uniform white light (CIE x=0.33, y=0.32) and includes a UV-stabilized coating (ISO 4892-2 compliant) to resist yellowing after 2,000 hours of sunlight exposure. The hermetically sealed housing (IP66-rated) protects against dust and water ingress, critical for proximity to fuel tanks.​
  • Mounting System: Fuel Tank-Integrated Design​
  • The Side Marker Lamp Mounting Bracket (3mm-thick galvanized steel, yield strength ≥ 350 MPa) is custom-engineered to attach directly to the fuel tank structure, featuring a contoured design that follows the tank’s profile for minimal air resistance and maximum structural alignment. Pre-drilled mounting holes (tolerance: ±0.15mm) ensure precise positioning, while reinforced gussets increase load-bearing capacity by 25%, resisting deformation from fuel tank vibrations or external impacts.​
  • Fastening System: Corrosion-Resistant Hardware​
  • A dual-layer fastening solution ensures secure, long-term installation:​
  • Hexagonal head bolt (zinc plated, ISO 4014) (M8 x 25mm, grade 8.8) penetrates the mounting bracket and fuel tank support, with an 8μm zinc coating (ASTM B633, 500 hours salt-spray resistance) that resists corrosion from fuel vapors and road salts.​
  • Type 2 all-metal hexagonal lock nut (zinc plated, DIN 980) provides vibration resistance, featuring a serrated flange that grips mating surfaces to maintain 95% clamping force after 100,000 cycle vibrations (ISO 16750-3 compliant). Torqued to 20–25 N·m, these nuts prevent loosening in high-vibration environments, such as off-road or highway operations.​
  • Material Excellence & Environmental Resilience​
  • Components are optimized for fuel tank proximity and extreme conditions:​
  • Fuel Resistance: The LED housing’s polycarbonate lens and bracket’s galvanized steel are tested to withstand 1,000 hours of exposure to diesel fuel (ASTM D975), showing ≤2% weight change and no material swelling—critical for safety in fuel-rich environments.​
  • Temperature Tolerance: Functions reliably from -40°C to +120°C, with the LED module’s aluminum heat sink (thermal conductivity: 180 W/m·K) dissipating heat efficiently and preventing thermal stress on the fuel tank surface.​
  • Mechanical Protection: The mounting bracket’s edges are rolled to 3mm radius to avoid abrasion on fuel tank coatings, while the lock nut’s zinc plating exceeds ISO 10683 for automotive fastener corrosion resistance.​
  • Compliance & Performance Benefits​
  • Key features enhance safety and fleet efficiency:​
  • Regulatory Adherence: Meets UN ECE R87 for side marker lights and SAE J1128 for commercial vehicle lighting durability, ensuring global certification and compliance with strict emissions and safety standards.​
  • Energy Efficiency: LED technology reduces power consumption by 40% compared to traditional incandescent lights, minimizing battery load and extending electrical system lifespan.​
  • Maintenance Ease: Modular design allows replacement of the LED Side Marker Lamp with Reflector in 15 minutes using standard tools, with color-coded wiring (white for marker lights) and labeled fasteners to simplify maintenance and reduce downtime.​
  • Testing & Reliability​
  • Rigorous validation ensures industry-leading performance:​
  • Vibration Fatigue Test: After 1,500 hours of 10–2,000 Hz vibration, Hexagonal head bolts and Type 2 lock nuts remain torqued within ±3% of specification, with no lamp displacement or bracket deformation detected.​
  • Salt-Spray Test: The zinc-plated fasteners and galvanized bracket pass 1,200 hours of ASTM B117 testing with ≤3% surface corrosion, confirming resilience in coastal or winter road conditions.​
  • Fuel Vapor Test: Maintains full functionality after 500 hours in a 50°C chamber with 50% diesel vapor concentration, with no LED performance degradation or housing cracks.​
  • Conclusion: Durable Side Markers for Fuel Tank Applications​

Product Parameters of Shacman X6000 Side Marker Lights (Fuel Tank)

NO Part.No Name Quantity
1 DZ91259721610 LED Side Marker Lamp with Reflector 1
2 DZ9X259810203 Side Marker Lamp Mounting Bracket 1
3 Q33205 Type 2 all-metal hexagonal lock nut (zinc plated) 2
4 Q33206 Type 2 all-metal hexagonal lock nut (zinc plated) 2
5 Q150B0620 Hexagonal head bolt (zinc plated) 2
