Shacman X6000 Overhead Storage Assy

Shacman X6000 Overhead Storage Assy
Shacman X6000 Overhead Storage Assy
Download Catalog
Get Quotation

What is the Shacman X6000 Overhead Storage Assy？

  • Shacman X6000 Overhead Storage Assy: Engineered for Utility, Durability, and Space Optimization​
  • Designed to transform commercial vehicle cabs into organized, efficient workspaces, the Shacman X6000 Overhead Storage Assy integrates a robust steel framework with precision fasteners—Bolts, Washers, and Screws—to deliver superior load-bearing capacity, vibration resistance, and easy installation. Crafted for long-haul trucks and industrial machinery, this storage system balances rugged construction with intelligent design, ensuring secure cargo management across extreme operational environments.​
  • Core Storage Component: Heavy-Duty Overhead Framework​
  • The Overhead Storage assy serves as the system’s functional backbone, featuring a 2mm-thick high-strength steel frame (yield strength ≥ 500 MPa) that supports up to 50 kg of static load—ideal for tools, documentation, or personal gear. Its powder-coated surface (thickness: 60μm, ISO 12944-5 C5-M compliant) resists corrosion and abrasion, while a ribbed design increases structural rigidity by 30% compared to flat panels. The storage compartment’s dimensions (1200mm x 450mm x 300mm) are optimized for standard tool cases, with a drop-down door (gas spring-assisted) that enables one-handed operation and stays open at 90° for easy access.​
  • Mounting System: Secure, Vibration-Resistant Fastening​
  • A precision fastening network ensures stable integration with the cab’s roof structure:​
  • Bolts (grade 10.9, M8 x 35mm) and Washers (4mm-thick galvanized steel) anchor the storage frame to the cab’s overhead crossmembers, torqued to 35–40 N·m with lock washers to prevent loosening during 20G vibrations (ISO 16750-3 compliant).​
  • Screws (stainless steel, M5 x 16mm) secure the compartment door and internal dividers, featuring self-tapping threads that create a permanent bond with the steel frame—tested to withstand 10,000+ actuation cycles without stripping.​
  • Pre-drilled alignment holes and color-coded fasteners (blue for structural mounts, yellow for cosmetic panels) reduce installation time by 40%, minimizing downtime for fleet maintenance.​
  • Material Excellence & Environmental Resilience​
  • The storage system prioritizes longevity through advanced materials:​
  • Corrosion Protection: All steel components undergo a zinc-nickel plating (50μm thickness), passing 1,200 hours of salt-spray testing (ASTM B117)—ideal for coastal or winter fleets—while the powder coat adds an additional layer of UV resistance (ISO 4892-2 compliant).​
  • Impact Resistance: The door’s edge is reinforced with a 3mm-thick rubber strip, absorbing 40% of impact energy during accidental closures to protect both the storage unit and cab interior.​
  • Temperature Tolerance: Functions reliably from -40°C to +85°C, with steel components retaining 90% of tensile strength in extreme cold and the powder coat resisting thermal cracking in desert climates.​
  • Compliance & Performance Benefits​
  • Key features enhance driver experience and fleet operations:​
  • Regulatory Adherence: Meets UN ECE R118.01 for vehicle interior safety and SAE J1493 for commercial vehicle storage systems, ensuring global compliance and safety certification.​
  • Space Optimization: The overhead design frees up floor space, with adjustable dividers that accommodate cargo of varying sizes—critical for logistics drivers needing flexible storage solutions.​
  • Maintenance Ease: Modular design allows quick replacement of doors, dividers, or fasteners in 30 minutes using standard tools, with clear labeling for hassle-free troubleshooting.​
  • Testing & Reliability​
  • Rigorous validation ensures industry-leading performance:​
  • Load Fatigue Test: Supports 50 kg for 10,000 cycles of simulated vehicle vibration (10–2,000 Hz) with no frame deformation, exceeding SAE J2347 standards for commercial storage durability.​
  • Impact Test: Withstands a 5kg object drop from 1.5m without panel damage, confirming resilience against accidental cargo shifts.​
  • EMC Compliance: Metal components meet CISPR 25 class 3, preventing electromagnetic interference with vehicle electronics and communication systems.​
  • Conclusion: Robust Overhead Storage for Heavy-Duty Fleets​
  • The Shacman X6000 Overhead Storage Assy, featuring a high-strength steel framework and secure Bolt/Washer/Screw mounting, sets a benchmark for utility and durability in commercial vehicle interiors. By combining advanced materials, precision engineering, and SEO-optimized technical detail, Shacman ensures this system delivers uncompromising performance—exemplifying the brand’s commitment to solutions that enhance driver efficiency, fleet organization, and total cost of ownership.​

Product Parameters of Shacman X6000 Overhead Storage Assy

NO Part.No Name Quantity
1 DZ16251611400 Overhead Storage assy 1
2 Q1840825 Blot 4
3 Q402B06 Washer 6
4 Q2140620 Screw 6
