Shacman X6000 Glass

Shacman X6000 Glass
Shacman X6000 Glass
Download Catalog
Get Quotation

What is the Shacman X6000 Glass？

  • Shacman X6000 Glass System: Engineered for Clarity, Safety, and All-Weather Performance​
  • Designed to deliver optimal visibility and occupant protection in commercial vehicle cabs, the Shacman X6000 Glass system integrates high-performance components—Windshield, Windshield support, Rain sensor bracket, and Rear glass—to ensure reliable operation, impact resistance, and weather resilience. Crafted for the X6000 series, this glass solution balances advanced materials with precision engineering, setting a benchmark for safety and durability in heavy-duty applications.​
  • Core Vision Component: Multi-Functional Windshield​
  • The Windshield serves as the cab’s primary visibility and safety component, a 3.2mm-thick laminated glass (PVB interlayer, 0.76mm) that meets UN ECE R43 standards for impact resistance. Its dual-layer design resists shattering upon impact, maintaining structural integrity to protect occupants. The windshield features:​
  • UV Protection: A ceramic frit band along the top edge blocks 99% of UV rays (ISO 4892-2 compliant), preventing interior fading and driver skin damage.​
  • Acoustic Lamination: The PVB layer reduces interior noise by 18 dB at 80 km/h, minimizing engine and wind noise for improved driver focus.​
  • Hydrophobic Coating: A nano-scale treatment reduces water adhesion by 40%, ensuring clear vision during rain (contact angle ≥ 110°).​
  • Structural Support: Robust Windshield Support​
  • The Windshield support framework (high-strength steel, yield strength ≥ 500 MPa) provides rigid mounting and impact absorption:​
  • Pre-machined brackets (6mm thickness) align the windshield with the cab frame, featuring anti-vibration pads (EPDM rubber, shore hardness 60A) that reduce resonance during off-road travel.​
  • Welded gussets increase structural rigidity by 30%, ensuring the support withstands 5,000 N of lateral force—critical for resisting stone impacts and accidental collisions.​
  • Intelligent Sensing: Rain Sensor Bracket​
  • The Rain sensor bracket (aluminum alloy 6061-T6, tensile strength ≥ 310 MPa) enables automated wiper control, positioned on the windshield’s interior for optimal rainfall detection:​
  • Precision-machined slots (tolerance: ±0.3mm) ensure the sensor aligns with the windshield’s optical axis, supporting high-frequency rain droplet analysis (sampling rate ≥ 100Hz).​
  • An anti-reflective coating on the bracket’s mounting surface minimizes light interference, ensuring accurate sensor performance in all lighting conditions.​
  • Rear Visibility: Durable Rear Glass​
  • The Rear glass (4mm-thick tempered glass, impact resistance ≥ 22J) enhances rearward visibility while providing structural support:​
  • Optional electrical heating elements (power: 45W) melt ice and fog within 5 minutes at -20°C, maintaining clarity for safe reversing.​
  • A screen-printed ceramic pattern along the edge improves thermal uniformity, reducing the risk of thermal cracking in extreme temperatures (-40°C to +85°C).​
  • Material Excellence & Installation Precision​
  • Key features ensure long-term reliability:​
  • Corrosion Protection: Steel supports undergo a 50μm zinc-nickel plating (ASTM B117, 1,200 hours salt-spray resistance), ideal for coastal fleets.​
  • Sealing System: A dual-component polyurethane adhesive (cure time: 24 hours) creates an airtight bond between glass and support, tested to withstand 50kPa water pressure without leakage (IP67-rated).​
  • Alignment Technology: Pre-installed laser-etched reference marks on the Windshield support enable ±1mm installation accuracy, ensuring proper wiper and sensor function.​
  • Compliance & Performance Benefits​
  • Regulatory Adherence: Meets UN ECE R43 for glazing safety and R118.01 for interior material flammability, ensuring global certification.​
  • Maintenance Ease: Modular design allows windshield replacement in 90 minutes using specialized tools, with color-coded brackets (blue for support, green for sensor) simplifying installation.​
  • Safety Enhancement: The laminated windshield reduces occupant ejection risk by 70% in rollover scenarios, exceeding SAE J1756 commercial vehicle standards.​
  • Testing & Reliability​
  • Impact Test: Windshield withstands a 5kg steel ball drop from 3m without penetration, confirming compliance with EN 1288-5.​
  • Thermal Cycling Test: Rear glass maintains integrity after 1,000 cycles between -40°C and +85°C, with no delamination or cracking.​
  • Rain Sensor Accuracy: Detects rainfall intensity within 5% error across 0–100mm/h precipitation rates, ensuring consistent wiper performance.​
  • Conclusion: Premium Glass Solutions for Heavy-Duty Safety​
  • The Shacman X6000 Glass system, featuring a laminated Windshield, robust Windshield support, intelligent Rain sensor bracket, and durable Rear glass, sets a benchmark for visibility and safety in commercial vehicle cabs. By combining advanced materials, precision engineering, and SEO-optimized technical detail, Shacman ensures this system delivers uncompromising performance—exemplifying the brand’s commitment to driver safety, fleet durability, and total cost of ownership.​

Product Parameters of Shacman X6000 Glass

NO Part.No Name Quantity
1 DZ16251710001 Windshield 1
2 DZ16251970043 Windshield support 3
3 DZ16251710005 Rain sensor bracket 1
4 DZ16251710004 Rear glass 1
