Shacman X6000 Front Stabilizer Assembly

Shacman X6000 Front Stabilizer Assembly
Shacman X6000 Front Stabilizer Assembly
Download Catalog
Get Quotation

What is the Shacman X6000 Front Stabilizer Assembly？

  • The Shacman X6000 Front Stabilizer Assembly is a precision-engineered system designed to enhance vehicle stability, reduce body roll during turns, and optimize handling performance for heavy-duty trucks. This assembly integrates advanced components to ensure durability and reliability under demanding driving conditions. Here’s a detailed breakdown of its key parts:
  • Bearing Pedestal Assembly
    The Bearing Pedestal Assembly provides a robust foundation for the stabilizer bar, ensuring smooth articulation and minimizing friction. Constructed from high-strength steel, it securely mounts to the chassis, supporting the dynamic forces generated during cornering and braking .
  • Bolt & Hexagon Flange Nut M7.112.40 M14*1.5-10-MAN183B1
    High-tensile bolts, paired with Hexagon Flange Nut M7.112.40 M14*1.5-10-MAN183B1, create a secure connection between the stabilizer bar and its supporting structures. The flange design of the nut distributes load evenly, while the M14x1.5 fine thread ensures vibration-resistant fastening .
  • Hexagon Flange Toothed Bolt – Fine Thread
    These specialized bolts feature a toothed flange that grips mating surfaces, preventing rotational movement. The fine thread design (M14x1.5) offers precise torque control, ideal for applications requiring high clamping force, such as attaching the stabilizer bar links .
  • Washer
    Flat washers are inserted between the bolt heads/nuts and mating surfaces to distribute pressure, reduce wear, and enhance joint integrity. Their inclusion ensures uniform load distribution across critical connections .
  • Front Stabilizer Bar UP Support
    The Front Stabilizer Bar UP Support reinforces the stabilizer bar’s mounting point, minimizing lateral deflection. Constructed from forged steel, it withstands heavy loads and aligns the bar to maintain optimal geometry during suspension travel .
  • Front Stabilizer Suspender Assembly
    This assembly connects the stabilizer bar to the vehicle’s control arms, transmitting forces to counteract body roll. The suspender links are engineered with precision ball joints for smooth articulation and durability, even on rough terrain .
  • Hexagon Head Bolt & Self-locking Nut
    Hexagon Head Bolts, combined with Self-locking Nuts, secure secondary components like brackets and braces. The self-locking mechanism prevents loosening due to vibration, ensuring long-term reliability without additional locking devices .
  • Bush
    Rubber bushings are strategically placed between metal components to dampen vibrations and reduce noise. These bushings absorb shocks from uneven roads, enhancing ride comfort while protecting the assembly from fatigue stress .
  • By integrating these components, the Shacman X6000 Front Stabilizer Assembly delivers superior stability and control, making it a critical upgrade for commercial vehicles. Each part is rigorously tested for strength and corrosion resistance, ensuring compliance with international standards for heavy-duty applications. For optimal performance, regular inspection and maintenance of the assembly are recommended.

Product Parameters of Shacman X6000 Front Stabilizer Assembly

NO Part.No Name Quantity
1 DZ9X259680007 Bearing Pedestal Assembly 2
2 DZ9X259680036 Bolt 2
3 06.11251.2005 Hexagon Flange Nut M7.112.40 M14*1.5-10-MAN183B1 4
4 Q1811440TF3 Hexagon Flange Toothed Bolt – Fine Thread 4
5 DZ9X259681018 Washer 4
6 DZ9H259680069 Front Stabilizer Bar UP Support 2
7 DZ9X259680044 Front Stabilizer Suspender Assembly 2
8 Q151B2090TF3 Hexagon Head Bolt 2
9 190003888467 Self-locking Nut 2
10 DZ9X259680029 Front Stabilizer Assembly 1
11 Q1811460TF3 Hexagon Flange Toothed Bolt – Fine Thread 4
12 81.43704.0074 Bush 2
