What is the Shacman X6000 Chassis Step Bracket_rh？

  • Shacman X6000 Chassis Step Bracketht-Hand Stability and Load Management
  • Engineered to deliver robust support for commercial vehicle step systems on the right-hand (RH) side, the Shacman X6000 Chassis Step Bracket_rh integrates a precision-engineered framework of high-strength brackets and durable fasteners—Front/Rear/Upper/Lower brackets-RH, Hexagon flange bolts, and Hexagon bolts/nuts—to ensure superior load distribution, vibration resistance, and long-term reliability. Designed for the X6000 series, this bracket assembly balances rugged mechanical design with adaptive engineering, ideal for logistics, construction, and off-road fleets.
  • Core Structural Components: Reinforced RH Bracket System
  • The Chassis bracket assy-RH forms the backbone of the step support structure, comprising four key components optimized for right-hand load dynamics:
  • Front bracket-RH (8mm-thick high-strength low-alloy steel, yield strength ≥ 550 MPa) anchors the forward mounting point, contoured to align with the vehicle’s frame rail and distribute 45% of dynamic loads (max 350 kg) to the chassis, minimizing stress on adjacent components.
  • Rear bracket-RH (6mm-thick quenched-tempered steel, tensile strength ≥ 650 MPa) reinforces the rear support, featuring a ribbed profile that increases shear resistance by 30%, critical for absorbing impacts from heavy equipment or frequent operator access.
  • Upper bracket-RH and Lower bracket-RH (5mm-thick hot-rolled steel) create a vertical load path, with pre-machined slots (tolerance: ±0.2mm) for precise alignment with step platforms and fender brackets, ensuring seamless integration with the cab’s exterior structure.
  • Mounting & Fastening: Vibration-Resistant Installation
  • A high-strength fastening network ensures secure integration with the vehicle chassis:
  • Hexagon flange bolts (grade 12.9, M14 x 60mm) secure the Front/Rear brackets-RH to the frame, torqued to 180–200 N·m with serrated washers to resist 25G vibrations (ISO 16750-3 compliant), maintaining 98% clamping force after 100,000 cycle fatigue testing—ideal for off-road roughness.
  • Hexagon bolts (grade 10.9, M12 x 50mm) and Nuts (self-locking, DIN 980V) connect the Upper/Lower brackets-RH, forming a rigid vertical axis that withstands 1,800 N of lateral force during sharp turns or uneven terrain, preventing step platform misalignment.
  • Material Excellence & Environmental Resilience
  • Components are optimized for harsh commercial environments:
  • Corrosion Protection: All steel brackets undergo a 50μm zinc-nickel plating (ASTM B117, 1,200 hours salt-spray resistance), while fasteners feature a lubricious coating to prevent galling, making them ideal for coastal or winter operations.
  • Temperature Tolerance: Functions reliably from -40°C to +120°C, with steel components retaining 90% of yield strength in arctic conditions and resisting thermal expansion in desert heat (coefficient ≤ 11×10⁻⁶/°C).
  • Wear Resistance: Bracket surfaces are shot-peened to enhance fatigue life, surviving 2.5 million cycles of simulated step loading (exceeding SAE J2347 standards), ensuring minimal wear over 10+ years of service.
  • Compliance & Performance Benefits
  • Key features enhance safety and fleet efficiency:
  • Regulatory Adherence: Meets EN 131-1:2021 for industrial step supports and ISO 6481 for vehicle mounting systems, ensuring global compliance and operator safety certification.
  • Load Efficiency: The bracket system reduces step platform deflection by 55% compared to generic mounts, extending the lifespan of step mats and fender covers by 20%.
  • Maintenance Ease: Modular design allows replacement of Front/Rear brackets-RH in 45 minutes using standard tools, with color-coded fasteners (blue for RH-specific components, red for high-torque bolts) to simplify identification and installation.
  • Testing & Reliability
  • Rigorous validation ensures industry-leading performance:
  • Static Load Test: Supports 1.5x rated load (525 kg) for 24 hours with ≤0.8mm deformation, exceeding SAE J1492 commercial vehicle step bracket standards.
  • Vibration Fatigue Test: After 1,500 hours of 10–2,000 Hz vibration, all fasteners remain torqued within ±3% of specification, with no bracket fractures detected via magnetic particle inspection.
  • Environmental Test: Maintains full functionality after 1,000 hours of exposure to salt fog and UV radiation, confirming resistance to corrosion and material degradation.
  • Conclusion: Heavy-Duty Right-Hand Support for Enduring Performance.

Product Parameters of Shacman X6000 Chassis Step Bracket_rh

NO Part.No Name Quantity
1 DZ16251240138 Front bracket-RH 1
2 DZ16251240132 Chassis bracket assy-RH 1
3 DZ16251240164 Rear bracket-RH 1
4 Q1860820 Hexagon flange bolt 8
5 DZ16251240168 Lower bracket-RH 1
6 Q151B1470T1F3 Hexagon bolt 2
7 Q151B14110TF3 Hexagon bolt 1
8 Q341B14T13F3 Nut 3
9 DZ16251240182 Upper bracket-RH 1
