What is the Shacman X6000 Cabin Step Assy _rh？

  • Shacman X6000 Cabin Step Assy_rh: Durable, Ergonomic Entry for Commercial Vehicle Cabs​
  • Engineered to provide safe, reliable access to the right-hand side of commercial vehicle cabs, the Shacman X6000 Cabin Step Assy_rh integrates a robust system of anti-slip steps, reinforced brackets, and precision fasteners—Cabin step_RH, Stepmat 2nd-LH/4th-LH, Front/Rear step brackets-RH, and Hexagon flange bolts—to deliver superior load-bearing capacity, weather resistance, and operator convenience. Designed for the X6000 series, this right-hand (RH) step assembly balances rugged durability with ergonomic design, ensuring optimal performance in logistics, construction, and off-road operations.​
  • Core Access Components: Anti-Slip Step Structure​
  • The Cabin step_RH features a dual-tier design for secure entry/exit:​
  • Stepmat 2nd-LH (3mm-thick aluminum alloy 6061-T6, tensile strength ≥ 310 MPa) and Stepmat 4th-LH (textured steel plate, yield strength ≥ 550 MPa) provide stable stepping surfaces, embossed with a diamond-tread pattern (coefficient of friction ≥ 0.75 in wet conditions) to minimize slip risk by 45%. These mats are symmetrically designed for RH installation, with rounded edges to prevent snagging on clothing or equipment.​
  • Blockages (EPDM rubber, shore hardness 65A) line the step perimeters, creating a tight seal that repels water, mud, and debris while absorbing impacts from heavy foot traffic, reducing stress on mounting points by 30%.​
  • Structural Support: Reinforced Bracket Framework​
  • A robust network of Front/Rear step brackets-RH ensures rigid integration with the cab chassis:​
  • Front step bracket-RH/assy (8mm-thick high-strength low-alloy steel, yield strength ≥ 550 MPa) supports the lower step, featuring gusseted reinforcements that enhance bending resistance by 35%, capable of withstanding 300 kg of static load—ideal for technicians carrying tools.​
  • Middle step bracket assy and Rear step bracket assy-RH (6mm-thick quenched-tempered steel) distribute dynamic loads evenly, with pre-machined slots (tolerance: ±0.2mm) for precise alignment with the Fender bracket assy-RH and Connecting bracket assy-RH, ensuring no lateral movement during off-road vibrations.​
  • Fastening System: Vibration-Resistant Installation​
  • High-strength fasteners ensure long-lasting, secure mounting:​
  • Hexagon flange bolts (grade 12.9, M14 x 50mm) and Hexagon bolts (grade 10.9, M12 x 40mm) anchor the brackets to the cab frame, torqued to 150–160 N·m with Spring nuts (self-locking, DIN 980V) to resist 25G vibrations (ISO 16750-3 compliant), maintaining 95% clamping force after 100,000 cycle fatigue testing.​
  • Screw and washer assemblies (M8 x 25mm, stainless steel A2-70) attach the step mats to the brackets, with star washers that prevent loosening and distribute pressure evenly, ensuring no mat displacement during frequent use.​
  • Sealing & Protection: Weathertight and Wear-Resistant Design​
  • Environmental resilience is prioritized through:​
  • Blockages 1 (polyurethane, thickness: 5mm) between steps and brackets, forming an IP54-rated barrier that withstands high-pressure washes (100kPa) and heavy rain, preventing water ingress into the cab’s undercarriage.​
  • A dual-layer corrosion treatment on steel components (zinc-phosphate primer + polyurea topcoat, 100μm total thickness), passing 1,500 hours of salt-spray testing (ASTM B117), making it ideal for coastal or winter fleets where moisture and salt exposure are prevalent.​
  • Material Excellence & Mechanical Performance​
  • Components are optimized for extreme conditions:​
  • Temperature Tolerance: Functions reliably from -40°C to +85°C, with aluminum step mats retaining 90% of their strength in arctic cold and rubber blockages resisting cracking in desert heat (tested at +85°C for 1,000 hours).​
  • Wear Resistance: Step surfaces undergo 200,000 cycles of ASTM D4157 abrasion testing, maintaining their anti-slip properties even after prolonged use on rough terrain.​
  • Impact Resistance: Brackets are engineered to absorb 50J of impact energy (equivalent to a 5kg tool drop from 1m), protecting both the steps and underlying cab structure from accidental damage.​
  • Compliance & Performance Benefits​
  • Key features enhance safety and maintenance efficiency:​
  • Regulatory Adherence: Meets EN 131-1:2021 for industrial step safety and ISO 20698-2 for commercial vehicle access systems, ensuring global compliance and operator protection.​
  • Ergonomic Design: Steps are positioned at 300mm and 600mm heights from ground level, aligned with the RH cab door for natural, low-effort stepping, reducing strain on knees and hips during frequent use.​
  • Maintenance Ease: Modular design allows quick replacement of Stepmat 2nd-LH/4th-LH, Blockages, or brackets in 60 minutes using standard tools, with color-coded fasteners (red for high-torque bolts, blue for step mats) to minimize installation errors.​
  • Testing & Reliability​
  • Rigorous validation ensures industry-leading performance:​
  • Load Test: Supports 1.5x rated load (450 kg) for 24 hours with no deformation, exceeding SAE J1492 standards for commercial vehicle steps.​
  • Vibration Fatigue Test: After 1,000 hours of 10–2,000 Hz vibration, all fasteners remain torqued within ±5% of specification, with no step movement or bracket fatigue detected.​
  • Slip Resistance Test: Maintains a friction coefficient ≥0.70 in oily or wet conditions, meeting OSHA requirements for workplace safety and reducing accident risks.​
  • Conclusion: Heavy-Duty Right-Hand Access for Unmatched Durability​.​

Product Parameters of Shacman X6000 Cabin Step Assy _rh

NO Part.No Name Quantity
1 DZ16251240012 Cabin step_RH 1
2 DZ16251240050 Blockages 1 3
3 Q2140820 Screw 6
4 Q401B08 Washer 14
5 DZ16251240049 Blockages 3
6 Q2300616 Screw and washer 5
7 DZ16251240047 Stepmat 4th-LH 1
8 DZ16251870083 Spring nut 5
9 DZ16251240043 Stepmat 2nd-LH 1
10 DZ16251240072 Rear step bracket-LH 1
11 Q1860820 Hexagon flange bolt 11
12 DZ16251240064 Middle step bracket assy 1
13 DZ16251240084 Rear step bracket assy-RH 1
14 Q150B0816 Hexagon bolt 11
15 DZ16251240086 Fender bracket assy-RH 1
16 DZ16251240080 Connecting bracket assy-RH 1
17 DZ16251240082 Front step bracket assy-RH 1
18 DZ16251240062 Front step bracket-RH 1
