Shacman X6000 Battery Spare Parts Catalog

Shacman X6000 Battery Spare Parts Catalog
Shacman X6000 Battery Spare Parts Catalog
Download Catalog
Get Quotation

What is the Shacman X6000 Battery Spare Parts Catalog？

  • The Shacman X6000 Battery Spare Parts Catalog offers a comprehensive range of OEM components designed to maintain, repair, and optimize the truck’s power system. Engineered for durability and safety, these parts ensure reliable battery performance in demanding commercial applications. Below is a detailed breakdown of key components and their technical specifications:
  • 1. Battery Box Assembly & Cover
  • The Battery Box Assembly forms a rugged enclosure for the battery, constructed from corrosion-resistant steel with a powder-coated finish to withstand moisture and debris. The matching Battery Box Cover features a weatherproof seal and quick-release latches, protecting the battery from external elements while enabling easy access for maintenance. Its reinforced design resists impact and ensures proper ventilation to prevent thermal buildup.
  • 2. Battery Fixing Long Bolt (260mm)
  • These 260mm-long fixing bolts secure the battery to the box, crafted from high-tensile steel with a zinc-plated coating for rust resistance. The extended length allows for secure clamping across multiple battery cells, while the hexagon head design ensures easy torque adjustment to prevent vibration-induced loosening.
  • 3. Spring Pressure Plate & U-shaped Spacer
  • The Spring Pressure Plate applies consistent downward force to the battery, preventing movement during transit. Made from heat-treated spring steel, it maintains tension over time to avoid damage from excessive vibration. Paired with the U-shaped Spacer, which provides lateral support and spacing between battery modules, this combination ensures a stable, noise-free installation.
  • 4. (Battery) Pole Guard & Maintenance-free Battery (180Ah)
  • The Pole Guard shields the battery terminals from short circuits and physical damage, constructed from flame-retardant plastic with a snap-fit design for quick installation. The catalog includes a 180Ah Maintenance-free Battery featuring calcium-alloy plates for reduced water loss and self-discharge, ideal for long-haul operations requiring minimal upkeep.
  • 5. Zinc-plated Hexagonal Head Bolts
  • Multiple zinc-plated hex bolts (varying lengths) secure battery brackets, boxes, and electrical components. Rated for high tensile strength, these bolts resist corrosion and provide reliable fastening in high-vibration environments. Their standardized hex head allows compatibility with common tools for efficient installation.
  • 6. Chassis Power Distribution Box & Electromagnetic Main Power Switch
  • The Chassis Power Distribution Box organizes electrical connections, featuring labeled terminals and circuit breakers for easy troubleshooting. The Electromagnetic Main Power Switch offers remote-controlled power cutoff, enhancing safety by isolating the battery during maintenance or emergencies. It meets IP67 standards for dust and water resistance.
  • 7. Mounting Brackets & Hardware
  • Electromagnetic Main Power Switch Mounting Bracket: Fabricated from stamped steel, this bracket positions the switch for easy access while withstanding engine bay vibrations.
  • Chassis Electrical Box Mounting Bracket: Designed for secure chassis integration, it features pre-drilled holes for precise alignment with vehicle mounting points.
  • Battery Box Connection Bracket: Links multiple battery boxes together, ensuring structural stability and electrical continuity.
  • 8. All-metal Hexagonal Locknuts (Type 2, Zinc-plated)
  • These Type 2 locknuts provide vibration-proof fastening for critical components, with a nylon insert that creates friction to prevent loosening. Zinc-plated for corrosion resistance, they are rated for heavy-duty applications and comply with ISO standards for reliability.
  • 9. Hexagonal Flange Face-bearing Surface with Toothed Bolt (Fine Thread)
  • Featuring a serrated flange to grip mating surfaces, these toothed bolts (fine thread M14×1.5) ensure non-slip installation for battery brackets and covers. The fine thread allows precise torque control, while the flange distributes load evenly to prevent surface damage.
  • 10. Hexagonal Nut M7.112.40 M14×1.5-10-MAN183B1 with Flange
  • This specialized nut meets MAN183B1 standards, offering high tensile strength (10-grade) with a serrated flange for anti-rotation security. Used in critical load-bearing connections, it ensures long-term reliability in harsh operating conditions.
  • The Shacman X6000 Battery Spare Parts Catalog integrates these components to deliver a cohesive solution for battery system maintenance. Each part undergoes rigorous testing for durability, electrical safety, and compatibility, ensuring seamless integration with the vehicle’s power architecture. Whether replacing worn components or upgrading for enhanced performance, this catalog provides OEM-quality parts that uphold Shacman’s standards for commercial vehicle reliability. Regular inspection of fasteners, terminals, and protective covers is recommended to maintain optimal battery function and extend service life.

Product Parameters of Shacman X6000 Battery Spare Parts Catalog

NO Part.No Name Quantity
1 DZ9X259760107 Battery box cover 1
2 DZ9L149760015 Battery fixing long bolt/260mm 2
3 DZ9L149760014 Spring pressure plate 2
4 DZ9X259760214 U-shaped spacer 2
5 81.25470.0035 (Battery) pole guard 4
6 DZ95189761480 Maintenance-free battery (180Ah) 2
7 Q150B0620 Hexagonal head bolts (zinc plated) 2
8 Q150B0525 Hexagonal head bolts (zinc plated) 2
9 DZ9X259712166 Chassis power distribution box 1
10 DZ97189763010 Electromagnetic main power switch 1
11 Q150B0614 Hexagonal head bolts (zinc plated) 8
12 DZ9X259760211 Electromagnetic main power switch mounting bracket 1
13 Q33205 All-metal hexagonal locknut type 2 (zinc plated) 2
14 DZ9X259712168 Chassis electrical box mounting bracket 1
15 Q1811440TF3 Hexagonal flange Face-bearing surface with toothed bolt-fine thread 4
16 06.11251.2005 Hexagonal nut M7.112.40 M14*1.5-10-MAN183B1 with flange 8
17 DZ9X259764002 Battery box connection bracket 2
18 Q1811450TF3 Hexagonal flange face-bearing surface with toothed bolt-fine thread 8
19 DZ9X259760100 Battery box assembly 1
20 Q33206 Type 2 all-metal hexagonal locknut (zinc-plated) 10
