FAW  Transmission Assembly-Output Shaft Assy

FAW  Transmission Assembly-Output Shaft Assy
FAW  Transmission Assembly-Output Shaft Assy
Download Catalog
Get Quotation

What is the FAW Transmission Assembly-Output Shaft Assy

  • The Output Shaft Assy is the critical power delivery component within the FAW Transmission Assembly. This precision-engineered shaft receives torque from the gear train and transmits it directly to the vehicle’s driveline. Its robust design incorporates multiple gear ratios, synchronizers for smooth engagement, and essential support elements, forming the core of the transmission’s output stage.
  • Core Power Transmission & Gear Stack: At its heart is the hardened Output Shaft, featuring integral splines or machined profiles. Mounted onto this shaft are key gear components: the 3Rd Speed Gear, 2Nd Speed Gear, Output Shaft Reverse Gear, and the Biaxial A Gear. These gears mesh with corresponding gears on the countershaft to provide the selected speed ratios. The Output Shaft Reverse Sliding Sleeve is crucial for reverse engagement, sliding to lock the reverse gear to the shaft when selected.
  • Synchronized Shifting Mechanism: Smooth gear changes are enabled by advanced synchronizer assemblies. The 1St/2Nd Synchronizer manages engagement between 1st and 2nd gears, while the 3Rd/4Th Synchronizer handles 3rd and 4th gears. These units utilize friction cones and blocker rings (Stop Ring) to match shaft speeds before gear engagement, preventing grinding and ensuring seamless shifts. A Washer For Spline is strategically placed to manage axial positioning and load distribution within the splined sections.
  • Precision Support & Axial Retention: Reliable rotation under high torque demands robust bearing support. This assembly utilizes a Cylindrical Roller Bearing Without Out Ring, indicating the outer race is likely integral to the transmission housing for precise alignment and maximum load capacity. Critical axial positioning of all components (gears, synchronizers, sleeves) is maintained by Circlips for Shaft installed in dedicated grooves. The Output Shaft Reverse Gear Washer provides specific axial spacing or thrust surface functionality for the reverse gear assembly. Final assembly and service access may involve specialized fasteners like the Hex Key.
  • This FAW Output Shaft Assy exemplifies transmission engineering excellence. It integrates multiple gear ratios, sophisticated synchronizers (1St/2Nd Synchronizer, 3Rd/4Th Synchronizer), robust bearing technology (Cylindrical Roller Bearing Without Out Ring), and secure retention (Circlip for Shaft, Washer For Spline, Output Shaft Reverse Gear Washer) on the core Output Shaft. This ensures efficient, smooth, and reliable power delivery from the FAW Transmission Assembly to the driving wheels.

Product Parameters of FAW  Transmission Assembly-Output Shaft Assy

Order Part NO. Part Name And Standards Oty
1700045-DY683 Transmission Assembly 1
1 10711105 Output Shaft 1
2 10641131 Hex Key 1
3 11841180-3 3Rd/4Th Synchronizer 1
4 10641122 Washer For Spline 5
5 10721113 3Rd Speed Gear 1
6 10711112 2Nd Speed Gear 1
7 10641128 Stop Ring 4
8 11841170-6 1St/2Nd Synchronizer 1
9 10711111 Biaxial A Gear 1
10 12051108 Output Shaft  Reverse Sliding Sleeve 1
11 12051110 Output Shaft Reverse Gear 1
12 10641130 Cylindrical Roller Bearing Without Out  Ring 1
13 Q43124 Circlip for Shaft 1
14 10641126 Output Shaft Reverse Gear  Washer 1
