What is the FAW Transmission Assembly-Outlet Pipe Module

  • Integrated Outlet Pipe Module for Efficient Fluid Management
    The FAW Transmission Assembly incorporates a dedicated Outlet Pipe Module, a critical subsystem engineered for optimal hydraulic fluid routing and thermal management. This module efficiently directs transmission fluid away from key operating components, ensuring consistent lubrication pressure and temperature control throughout the system. Its strategic placement and robust design are essential for maintaining the transmission’s overall efficiency and longevity under demanding operating conditions.
  • Precision Gearbox Linkage Components
    Central to the module’s operation is its interface with the auxiliary drivetrain via the Front Auxiliary Box Fork. This forged linkage component, working in conjunction with the Front Auxiliary Box Fork Block and the Front Auxiliary Box Fork Shaft, translates shift commands into precise mechanical movement within the auxiliary gearbox. This trio of components ensures reliable power transfer to secondary drives while maintaining critical alignment with the main transmission assembly.
  • Secure Alignment with Precision Engineering
    Accurate positioning of the Outlet Pipe Module relative to the transmission housing is ensured by a critical Cylindrical Pin. This precision-ground dowel pin provides shear strength and maintains exact radial alignment during assembly, preventing micro-movement that could compromise fluid seals or linkage geometry. The pin’s installation represents FAW’s commitment to dimensional accuracy in high-stress connection points, directly contributing to the system’s leak-free performance and vibration resistance over extended service life.

Product Parameters of FAW Transmission Assembly-Outlet Pipe Module

Order Part NO. Part Name And Standards Oty
1700045-DY683 Transmission Assembly 1
1 10642059 Cylindrical Pin 1
2 10642058 Front Auxliary Box Fork 1
3 10641095 Front Auxliary Box Fork Block 2
4 10642065 Front Auxliary Box Fork Shaft 1
