What is the FAW Engine Aseembly-Oil Dipstick Group

  • 1. Essential Engine Oil Level Monitoring
    The Oil Dipstick Group provides the critical manual measurement point for monitoring engine lubrication oil level within the FAW WP13.550E501 Engine Assembly. This assembly ensures operators can perform quick, accurate oil level checks during daily inspections and maintenance, vital for preventing engine damage due to under-lubrication or overfilling.
  • 2. Core Components & Function
  • Dipstick Assembly: The primary tool, featuring a calibrated measurement rod and handle. Inserted into the Dipstick Pipe Below Set, it provides a visual gauge of oil level against marked indicators (Low/Full).
  • Dipstick Pipe Below Set (Guide Tube): A fixed tube permanently mounted to the engine block or oil pan. It precisely guides the dipstick to the correct oil sump depth and prevents bending or misplacement.
  • Rubber Hoop (Sealing Grommet): A flexible, oil-resistant seal located at the top of the guide tube. It creates a dust-tight, splash-proof seal around the dipstick shaft, preventing dirt ingress and oil mist leakage while allowing easy insertion/removal.
  • 3. Secure Mounting & Vibration Resistance
  • Pipe Clamp: A sturdy metal clamp securing the Dipstick Pipe Below Set firmly to the engine block or adjacent structure. This prevents tube movement or vibration fatigue during engine operation.
  • Hexagon Flange Bolt: The high-strength fastener used to attach the Pipe Clamp. Its integral flange distributes clamping load evenly, while the bolt’s design provides superior resistance to loosening caused by engine vibration, ensuring the guide tube remains stable for accurate readings.
  • 4. Importance for Engine Health & Longevity
    Regular oil level checks using this group are fundamental preventative maintenance. A properly functioning assembly ensures:
  • Accurate Measurement: The stable Dipstick Pipe Below Set guarantees the dipstick reaches the correct depth every time.
  • Contamination Prevention: The Rubber Hoop effectively seals the system.
  • Reliable Mounting: The Pipe Clamp and vibration-resistant Hexagon Flange Bolt keep the guide tube securely fixed.
    Failure can lead to incorrect oil level readings, potential contamination, or tube damage, risking catastrophic engine failure from oil starvation or dilution.
  • 5. FAW OEM Quality for Reliable Operation
    Manufactured to precise FAW specifications, every component – the durable Dipstick Assembly, rigid Dipstick Pipe Below Set, sealing Rubber Hoop, robust Pipe Clamp, and high-grade Hexagon Flange Bolt – ensures consistent performance and longevity. Genuine FAW parts guarantee perfect fitment, material compatibility with hot engine oil, and resistance to harsh underhood environments, safeguarding the WP13.550E501’s lubrication system integrity.

Product Parameters of FAW Engine Aseembly-Oil Dipstick Group

Order Part NO. Part Name And Standards Oty
  1000410A-DY889R WP13.550E501  Engine Aseembly 1
1 1000284519 Dipstick Assembly 1
2 612600010446 Rubber Hoop 2
3 612600010647 Pipe Clamp 1
4 90011400019 Hexagon flange bolt 1
5 1003085310 Dipstick Pipe Below Set 1
