Sitrak Narrow-Body Medium-Length Cab Lower Berth (With Lower Berth Guard)

Sitrak Narrow-Body Medium-Length Cab Lower Berth (With Lower Berth Guard)
Sitrak Narrow-Body Medium-Length Cab Lower Berth (With Lower Berth Guard)
Download Catalog
Get Quotation

What is the Sitrak Narrow-Body Medium-Length Cab Lower Berth (With Lower Berth Guard)

  • The Sitrak Narrow – Body Medium – Length Cab Lower Berth (With Lower Berth Guard) is a well – designed and robust component tailored for the specific needs of narrow – body medium – length cabs. It offers a comfortable and safe resting space for drivers during long – haul journeys.
  • The core of this setup is the Narrow – body medium – length cab lower bunk assembly (with lower bunk guard). This assembly is engineered to fit precisely within the narrow – body cab, providing a stable and secure platform for the lower berth. The lower bunk guard adds an extra layer of safety, preventing the occupant from accidentally rolling off the berth during movement.
  • The Lower bunk left support assembly and Lower bunk right support assembly (symmetrical with left piece) play a crucial role in bearing the weight of the lower berth and its occupant. These support assemblies are constructed with high – strength materials to ensure durability and reliability. They are symmetrically designed to evenly distribute the load, enhancing the overall stability of the lower berth.
  • The Left Clamp and Right clamp (symmetrical to left) are used to firmly hold the various components of the lower berth together. They provide a secure connection, preventing any unwanted movement or rattling during the vehicle’s operation. The Center bearing further enhances the structural integrity of the lower berth, ensuring smooth weight distribution and reducing stress on individual components.
  • The Sleeper left support tube and Sleeper right support tube (symmetrical to left piece) offer additional support to the lower berth. They are strategically placed to reinforce the structure and provide a stable base. The Spacer tube is used to maintain the proper spacing between different parts of the assembly, ensuring that all components work in harmony.
  • To assemble these components securely, a variety of fasteners are used. Hexagon head bolts are employed to provide a strong and reliable connection. Paired with Flat washers, they distribute the clamping force evenly, preventing damage to the components. Open end flat garden head break mandrel rivets are used for a more permanent and vibration – resistant connection. Cross recessed pan head screws offer a convenient way to fasten smaller parts, and Blind rivet nuts M8 provide a secure anchor point for other components.
  • In summary, the Sitrak Narrow – Body Medium – Length Cab Lower Berth (With Lower Berth Guard) is a comprehensive and well – thought – out solution. With its precisely engineered components and reliable fastening methods, it provides a comfortable, safe, and durable resting space for drivers in narrow – body medium – length cabs. This product is a testament to Sitrak’s commitment to quality and functionality in commercial vehicle interiors.

Product Parameters of Sitrak Narrow-Body Medium-Length Cab Lower Berth (With Lower Berth Guard)

810-#09R0-0156  Narrow-Body Medium-Length Cab Lower Berth (With Lower Berth Guard)
Serial No.  Drawing No. Name Quantity
1 810-62159-6375 Narrow-body medium-length cab lower bunk assembly (with lower bunk guard) 1
2 810-62158-5039 Lower bunk left support assembly 1
3 810-62158-5038 Lower bunk right support assembly (symmetrical with left piece) 1
4 810-62159-0237 Left Clamp 1
5 810-62159-0236 Right clamp (symmetrical to left) 1
6 810-62158-2030 Center bearing 2
7 810-62158-0037 Sleeper left support tube 1
8 810-62158-0038 Sleeper right support tube (symmetrical to left piece) 1
9 810-94289-0199 Spacer tube 4
10 Q150B0825F31 Hexagon head bolts 4
11 Q40108F31 Flat washers 4
11 Q40108F31 Flat washers 4
12 Q4400510T19 Open end flat garden head break mandrel rivets 6
13 Q2140835F31 Cross recessed pan head screws 4
14 MQ6W13169-0021 Blind rivet nuts M8 4
810-62158-5038 Lower bunk right support assembly (symmetrical to left piece)
Serial No.  Drawing No. Name Quantity
0 810-62158-2042 Lower sleeper right bracket (symmetrical to left piece) 1
0 810-62158-2016 Pins 1
