Sitrak G7H Premium Edition Combination Instrument and Control System (Fuel National 5)

Sitrak G7H Premium Edition Combination Instrument and Control System (Fuel National 5)
Sitrak G7H Premium Edition Combination Instrument and Control System (Fuel National 5)
Download Catalog
Get Quotation

What is the Sitrak G7H Premium Edition Combination Instrument and Control System (Fuel National 5)

  • Sitrak G7H Premium Edition Combination Instrument and Control System (Fuel/National 5): Precision Monitoring and Advanced Control for Heavy-Duty Vehicles​
  • Engineered to redefine performance and efficiency in heavy-duty transportation, the Sitrak G7H Premium Edition Combination Instrument and Control System (Fuel/National 5) integrates cutting-edge technology with robust components to ensure seamless operation and precise fuel management. Designed to meet stringent National 5 emissions standards, this system combines intuitive monitoring with advanced control features, making it an ideal choice for modern commercial fleets.​
  • At the core of the system, the Electrical Junction Box Assembly serves as the central hub for all electrical connections. It organizes and protects the intricate wiring network, ensuring reliable signal transmission and power distribution. This assembly is securely fastened using a combination of Cross recessed pan head screws, Flat Washers, and Large Washers, which work together to prevent loosening due to vibrations during vehicle operation. The flat washers distribute the clamping force evenly, while the large washers enhance the stability of the connection, protecting the junction box from potential damage.​
  • The C7H-TFT Fuel Gauge provides real-time, accurate readings of the fuel level, allowing drivers to monitor consumption and plan refueling stops efficiently. Its high-resolution TFT display offers clear visibility in various lighting conditions, ensuring that critical information is always accessible. The gauge is calibrated to meet the precise requirements of the Sitrak G7H, ensuring seamless integration with the vehicle’s fuel system.​
  • The NanoBCU Controller acts as the brain of the system, processing data from multiple sensors and controlling various functions with pinpoint accuracy. This advanced controller is mounted securely on the NanoBCU Mounting Bracket, which is attached to the vehicle using Hexagonal flange face bolts M6, Spring washers, and Large washers. The spring washers prevent the bolts from loosening under vibration, while the hexagonal flange face design ensures a stable and secure connection. The NanoBCU Controller’s sophisticated algorithms optimize fuel usage, contributing to improved fuel efficiency and reduced emissions, in line with the National 5 standards.​
  • The FRC Cross Channel plays a crucial role in facilitating communication between different components of the system. It ensures that data is transmitted quickly and accurately, enabling seamless coordination of the instrument and control functions. The assembly of the FRC Cross Channel is reinforced with Cross recessed pan head screws, Flat Washers, and Spring washers, providing a robust and reliable connection.​
  • For added durability and stability, the system employs a variety of high-quality fasteners. Cross recessed pan head screws stainless steel (Q2140816) offer superior corrosion resistance, ensuring long-term reliability in harsh operating environments. Hexagon nuts type I and Cross recessed pan head tapping screws are used in key areas to secure components firmly, while Electrical Mounting Bracket Assembly provides a sturdy framework for the entire system, ensuring that all parts remain in place even under heavy vibrations and extreme conditions.​
  • SEO-Optimized Features​
  • Keyword Precision: Incorporates the full product name, model-specific details, and key component names to target exact-match searches in parts catalogs, technical resources, and industry databases.​
  • Technical Depth: Details the function and importance of each component, highlighting technological advancements, material quality, and performance benefits to attract automotive professionals and fleet managers.​
  • Benefit-Driven Messaging: Emphasizes precision monitoring, advanced control, fuel efficiency, and compliance with emissions standards, addressing the key concerns of heavy-duty vehicle operators and owners seeking reliable and eco-friendly solutions.​
  • In summary, the Sitrak G7H Premium Edition Combination Instrument and Control System (Fuel/National 5) sets a new standard for performance and reliability in heavy-duty vehicles. With its advanced components, secure mounting, and intelligent control features, it offers a comprehensive solution for efficient fuel management and seamless vehicle operation, making it an indispensable asset for modern commercial fleets.

Product Parameters of Sitrak G7H Premium Edition Combination Instrument and Control System (Fuel National 5)

712-#0502-0021 G7H Premium Edition Combination Instrument and Control System (Fuel/National 5)
Serial No. Drawing No.  Name Quantity
1 WG9716582301 Electrical Junction Box Assembly 1
2 Q40106 Flat Washer 4
2 Q40106 Flat Washers 1
3 Q2140616 Cross recessed pan head screws 4
4 WG9716582214 C7H-TFT Fuel Gauge 1
5 WG9716582011 NanoBCU Controller 1
12 811W25441-0726 FRC Cross Channel 1
13 Q40206 Large Washers 3
14 Q2140612 Cross recessed pan head screws 3
15 Q340B06 Hexagon nuts type I 3
16 YZ9003820002 Cross recessed pan head screws stainless steel (Q2140816) 6
17 ZQ1840616 Hexagonal flange face bolts M6 2
18 Q40208F31 Large washers 2
19 Q40308F31 Spring washers 2
19 Q40308F31 Spring washers 4
20 Q2140820F31 Cross recessed pan head screws 4
21 Q40108F31 Flat washers 4
22 Q40306 Spring Washers 4
22 Q40306 Spring washers 1
23 Q2140510 Cross recessed pan head screws 1
24 Q40305 Spring washers 1
25 Q40105 Flat Washers 1
26 Q2140610 Cross recessed pan head screws 1
27 Q2714816F31 Cross recessed pan head tapping screws 4
28 Q40205 Large Washers 4
29 YG9600580002 NanoBCU Mounting Bracket 1
30 YG9600580007 Electrical Mounting Bracket Assembly 1
WG9716582301 Electrical Junction Box Assembly
Serial No. Drawing No.  Name Quantity
1 WG9716582301/1 Electrical Junction Box (Sichuan Panhua) 1
2 WG9716582301/2 Electrical Junction Box (Ya’an Xiaohang) 1
3 WG9716582301/3 Electrical Junction Box (Dongguan Yaoya) 1
WG9716582301/1 Electrical junction box (Sichuan Panhua)
Serial No. Drawing No.  Name Quantity
1 WG9716582301+001/1 5A Chip Fuse (Sichuan Panva)) 4
2 WG9716582301+002/1 7.5A Chip Fuse (Sichuan Panva) 1
3 WG9716582301+003/1 10A Chip Fuse (Sichuan Panva) 16
4 WG9716582301+004/1 15A Chip Fuse (Sichuan Panhua) 15
5 WG9716582301+005/1 20A Chip Fuse (Sichuan Panhua) 4
6 WG9716582301+006/1 25A Chip fuse (Sichuan Panhua) 5
7 WG9716582301+007/1 40A Chip Fuse (Pan-China) 1
8 WG9716582301+008/1 20A normally open relay (Pan-China) 6
9 WG9716582301+009/1 40A normally open relay (Panchina) 2
10 WG9716582301+010/1 40A Duplex Relay (Pan-China) 2
11 WG9716582301+011/1 70A Normally Open Relay (Pan-China) 1
12 WG9716582301+012/1 Diode (Sichuan Panhua) 2
13 WG9716582301+013/1 40A Switching Relay (Pan-China) 2
WG9716582301/2 Electrical Junction Box (Ya’an Xiaohang)
Serial No. Drawing No.  Name Quantity
1 WG9716582301+001/2 5A Chip Fuse (Ya’an Xiaohang)) 4
2 WG9716582301+002/2 7.5A Chip Fuse (Ya’an Xiaohang) 1
3 WG9716582301+003/2 10A Chip Fuse (Ya’an Xiaohang) 16
4 WG9716582301+004/2 15A Chip Fuse (Ya’an Xiaohang) 15
5 WG9716582301+005/2 20A Chip Fuse (Ya’an Xiaohang) 4
6 WG9716582301+006/2 25A Chip fuse (Ya’an Xiaohang) 5
7 WG9716582301+007/2 40A Chip Fuse (Ya’an Xiaohang) 1
8 WG9716582301+008/2 20A Normally Open Relay (YaHang) 6
9 WG9716582301+009/2 40A Normally Open Relay (YaHang) 2
10 WG9716582301+010/2 40A Duplex Relay (YaHang) 2
11 WG9716582301+011/2 70A Normally Open Relay (YaHang) 1
12 WG9716582301+012/2 Diode (YaHang) 2
13 WG9716582301+013/2 40A Switching Relay (YaHang) 2
WG9716582301/3 Electrical Junction Box (Dongguan Yaoya)
Serial No. Drawing No.  Name Quantity
1 WG9716582301+001/3 5A Chip Fuse (Dongguan Yaoya) 4
2 WG9716582301+002/3 7.5A Chip Fuse (Dongguan Yaoya) 1
3 WG9716582301+003/3 10A Chip Fuse (Dongguan Yaoya) 16
4 WG9716582301+004/3 15A Chip Fuse (Dongguan Yaoya) 15
5 WG9716582301+005/3 20A Chip Fuse (Dongguan Yaoya) 4
6 WG9716582301+006/3 25A Chip Fuse (Dongguan Yaoya) 5
7 WG9716582301+007/3 40A Chip Fuse (Dongguan Yaoya) 1
8 WG9716582301+008/3 20A Normally Open Relay (Dongguan Yaoya) 6
9 WG9716582301+009/3 40A Normally Open Relay (Dongguan Yaoya) 2
10 WG9716582301+010/3 40A Duplex Relay (Dongguan Yaoya) 2
11 WG9716582301+011/3 70A Normally Open Relay (Dongguan Yaoya) 1
12 WG9716582301+012/3 Diode (Dongguan Yaoya) 2
13 WG9716582301+013/3 40A Switching Relay (Dongguan Yaoya) 2
YG9600580002 NanoBCU mounting bracket
Serial No. Drawing No.  Name Quantity
25 YG9600580002/1 1
26 YG9600580002/2 0
YG9600580007 Electrical fixing bracket assembly
Serial No. Drawing No.  Name Quantity
25 YG9600580007/1 1
26 YG9600580007/2 1
AC97165820129 C7H Electrical Junction Box Nameplate (NanoBCU/Premium)
Serial No. Drawing No.  Name Quantity
1 WG9716582129 C7H Electrical Junction Box Nameplate (NanoBCU/Premium Edition) 1
