FAW Solenoid Valve Logic Assembly

FAW Solenoid Valve Logic Assembly
FAW Solenoid Valve Logic Assembly
Download Catalog
Get Quotation

What is the FAW Solenoid Valve Logic Assembly

  • The FAW Solenoid Valve Logic Assembly serves as the central electronic brain for precisely managing fluid flow (hydraulic or pneumatic) in critical FAW vehicle systems. This sophisticated module interprets sensor data and control unit commands, rapidly energizing or de-energizing solenoid coils to open or close valves with exceptional accuracy. Engineered for FAW’s specific applications, it ensures optimal system response, efficiency, and reliability under demanding operating conditions, playing a vital role in functions like transmission shifting or advanced suspension control.
  • FAW Assembling Bolt: Precision Fastening for Critical Components
  • The FAW Assembling Bolt provides the fundamental threaded fastening required to securely join components of the solenoid valve system to mounting points, brackets, or housings within the FAW vehicle. These bolts are manufactured to precise FAW specifications for tensile strength and thread pitch, ensuring a vibration-resistant hold that maintains the integrity and precise positioning of the sensitive logic assembly and valve bodies over the long term.
  • FAW Hexagon Nut: Secure Locking for Threaded Fasteners
  • Working in tandem with bolts, the FAW Hexagon Nut delivers reliable, easily serviceable fastening for the solenoid valve assemblies. Its six-sided design allows for standard wrench application, ensuring proper torque can be achieved during installation and maintenance. These nuts are specified by FAW for their consistent performance and ability to maintain critical clamping force, preventing loosening due to engine or road vibration that could compromise system function.
  • FAW Two-Link Solenoid Valve Bracket Assembly: Dedicated Mounting Platform
  • The FAW Two-Link Solenoid Valve Bracket Assembly is a purpose-engineered structural platform designed specifically to mount and align two linked solenoid valves within the FAW system. This robust bracket ensures the valves are held securely in their optimal operational position, isolated from excessive vibration, and provides necessary clearance for wiring harnesses and fluid lines. Its design guarantees precise valve orientation crucial for consistent fluid dynamics.
  • FAW Two-Link Solenoid Valve Assembly: Coordinated Fluid Flow Control
  • The FAW Two-Link Solenoid Valve Assembly consists of two electronically controlled solenoid valves mechanically or functionally linked to manage complex fluid pathways within a single FAW subsystem. This integrated unit allows for sequenced or simultaneous operation, enabling advanced control strategies like pressure modulation or flow diversion. Built to FAW’s exacting standards, it offers synchronized performance and compact design efficiency.
  • FAW Cross Recessed Button Head Screw: Low-Profile, Secure Fastening
  • Used for attaching covers, sensors, or smaller components to the solenoid assemblies or brackets, the FAW Cross Recessed Button Head Screw offers a combination of security and a low-profile finish. The recessed Phillips (cross) drive allows for firm tightening, while the button head sits nearly flush with the mounting surface. This minimizes snagging points and contributes to a clean, professional assembly, meeting FAW’s quality and safety standards.
  • FAW Solenoid Valve Bracket: Essential Component Support & Alignment
  • The FAW Solenoid Valve Bracket (singular or as part of an assembly) provides the critical structural support and precise positioning for individual solenoid valves within the FAW system. This bracket ensures the valve body is rigidly mounted, correctly oriented for fluid line connections, and protected from misalignment or stress that could affect performance or longevity. Its design is optimized for the specific valve type and FAW vehicle mounting location.

Product Parameters of FAW Solenoid Valve Logic Assembly

Order Part NO. Part Name And Standards Oty
Solenoid  Valve Logic Assembly
1 CQ1461030 Assembling Bolt 2
2 CQ34010 Hexagon Nut 2
3 3754010-87S Two-Link Solenoid Valve Bracket  Assembly 1
4 3754020-57H Two-Link  Solenoid Valve Assembly 1
5 Q2320410 Cross Recessed Button Head  Screw 8
6 3754016-87S Solenoid  Vavle Bracket 1
