FAW Side Toolbox Module

FAW Side Toolbox Module
FAW Side Toolbox Module
Download Catalog
Get Quotation

What is the FAW Side Toolbox Module

  • FAW Side Toolbox Module provides essential, secure external storage integrated directly into the chassis of FAW commercial vehicles. Engineered for rugged durability and easy access, this lockable compartment system offers weather-protected space for tools, equipment, and essential spares, maximizing utility and workflow efficiency for drivers and operators in demanding environments.
  • Enclosure & Access Covers
  • Side Enclosure Right Toolbox Cover Assembly & Side Enclosure Left Toolbox Cover Assembly: The primary, heavy-duty hinged doors providing access to the toolbox compartments on the right and left sides of the vehicle. Constructed from impact-resistant materials.
  • Side Enclosure Toolbox Cover Assembly: General term encompassing the design and construction of these robust access panels.
  • Hinge & Opening Mechanism
  • Tool Box Cover Hinge Assy: Robust hinges enabling smooth opening and secure closing of the toolbox covers. Designed for repeated use and to withstand constant vibration and load stress.
  • Opening Handle-Toolbox: The primary grip mechanism for operators to easily open the toolbox covers.
  • Handle Assembly-Front Panel: Likely refers to the mounting hardware or bracket integrating the opening handle with the toolbox cover structure.
  • Locking & Security System
  • Right Lock Pin Assembly-Side Toolbox & Left Lock Pin Assembly-Side Toolbox: The primary mechanical pins or bolts that securely latch the right and left toolbox covers in the closed position during transit.
  • Right Side of the Toolbox Lock Assembly & Left Side of the Toolbox Lock Assembly: Complete lock mechanisms (potentially including key cylinders, latches, and strikers) providing security for the toolbox contents on each side. Prevents unauthorized access.
  • Assist & Positioning System
  • Air Spring Assembly-Side Toolbox: Gas struts that provide controlled lifting assistance. They make opening heavy toolbox covers easier and safer for the operator, and securely hold the covers open during access, preventing accidental closure.
  • Sealing & Weather Protection
  • Side Toolbox Seal Strip: A continuous, durable weatherstrip gasket running around the perimeter of the toolbox opening. Creates a critical watertight and dustproof seal when the cover is closed, protecting contents from rain, road spray, and debris.
  • Critical Mounting Hardware
  • Cross Recessed Button Head Screw: Provides a low-profile, clean finish for attaching components like hinge plates, handle mounts, lock assemblies, and trim. Resists snagging and offers good corrosion resistance.
  • Assembling Bolt: High-strength bolts used for structural connections, such as mounting hinge assemblies or lock supports to the chassis or toolbox body, ensuring long-term security under load and vibration.
  • This integrated module exemplifies FAW’s focus on operator convenience and vehicle utility, delivering secure, accessible, and weather-protected external storage through robust construction, reliable locking, assisted opening, and effective sealing.

Product Parameters of FAW Side Toolbox Module

Order Part NO. Part Name And Standards Oty
Side Toolbox Module 1
1 5407020-B45 Side  enclosure right toolbox cover Assembly 1
2 5407025-B45 Side enclosure toolbox cover  Assembly 2
4 5407060-B45-C00 Tool Box Cover Hinge Assy 4
5 Q2360616F6 Cross Recessed Button Head  Screw 8
6 5407050-B45-C00 Air Spring Assembly-Side  Toolbox 4
7 5302180-A01 Handle  Assembly-Front Panel 2
8 CQ1460616F6 Assembling Bolt 8
9 5407210-B45-C00 Right  Lock Pin Assembly-Side Toolbox 1
Side  enclosure left toolbox cover Assembly
11 5407015-B45 1
12 5407205-B45-C00 Left Lock Pin Assembly-Side  Toolbox 1
13 5407086-B45-C00 Side Toolbox Seal Strip 2
14 5407090-B45-C00 Opening Handle-Toolbox 2
15 5407410-B83-C00 Right Side of the toolbox lock  Assembly 1
16 5407405-B83-C00 Left Side of the toolbox lock  Assembly 1
