What is the FAW Right Chassis Wire Harness Logic Assembly

  • FAW Right Chassis Wire Harness Logic Assembly: Intelligent Control & Protection for Critical Right-Side Systems
  • The FAW Right Chassis Wire Harness Logic Assembly integrates advanced electronics with rugged wiring to manage critical systems along the passenger-side (right-side) chassis of FAW commercial trucks. This assembly combines the Right Chassis Wire Harness Assembly – a heavy-duty wiring network – with an intelligent Logic Module that processes data from right-side sensors (ABS wheel speed, suspension height, lighting, brake pressure) and controls actuators (right brake valves, lift mechanisms, trailer connectors). Its “logic” enables real-time diagnostics, coordinated responses for stability systems, and compliance with safety regulations specific to right-side operations.
  • Intelligent Control Module
  • The embedded Logic Module serves as the system’s brain, interpreting sensor signals and executing control algorithms for:
  • Right-wheel ABS/EBS modulation
  • Trailer light synchronization
  • Suspension load balancing
  • Fault diagnostics (storing DTCs for right-side circuits)
    Sealed within a vibration-resistant housing, it ensures reliable performance in harsh under-chassis environments.
  • Environmental Defense System
  • Four strategically placed Plastic Shields provide multi-layer defense:
  • Harness Trunk Shield: Guards main cable runs against flying debris.
  • Connector Hoods: Protect ECU and sensor junctions from moisture.
  • Exhaust Proximity Shield: Heat-resistant barrier near mufflers.
  • Frame Rail Shield: Prevents abrasion against chassis edges.
    A Rubber Seal Ring creates IP67-rated sealing at module entry points, blocking water/dust ingress.
  • Secure Routing & Vibration Resistance
  • Cable Ties + Cable Ties Card Socket: Nylon ties anchor harness branches to chassis-mounted sockets, enabling service-friendly reattachment.
  • Plastic Tie Band Assembly: Heavy-duty buckle bands secure main harness trunks with 500N+ tensile strength, surviving extreme vibration.
  • Shielded Routing Paths: Harness is routed away from heat sources, moving parts, and sharp edges using angled clips.

Product Parameters of FAW Right Chassis Wire Harness Logic Assembly

Order Part NO. Part Name And Standards Oty
Right Chassis Wire Harness Logic  Assembly 1
1 3724265X-DY683 Right Chassis Wire Harness  Assembly 1
2 3723011-81W-C00 Cable Ties 30
3 3724031-14C Rubber Seal Ring 1
4 3724114-240 Cable Ties Card Socket 2
5 3724115-240 Plastic Tie Band Assembly 2
6 QF2B4008 Plastic Shield 4
7 QF2B5008 Plastic Shield 2
8 QF2B4006 Plastic Shield 2
9 QF2B6008 Plastic Shield 1


Related FAW Truck Spare Parts
