What is the FAW Clutch Logic Assembly

  • The FAW Clutch Logic Assembly represents a sophisticated, pre-integrated module engineered for precise clutch actuation and control within FAW vehicles. This assembly seamlessly integrates mechanical components, hydraulic/pneumatic elements, and critical hardware to deliver reliable power transfer management between the engine and transmission.
  • Core Clutch Mechanism & Power Transfer: The foundation lies in the Clutch Cover Assy, housing the pressure plate mechanism, and the Clutch Driven Disc Assembly, featuring friction material and torsional dampening springs. Engaging and disengaging this assembly is the precision Clutch Release Bearing Assy, which applies force to the clutch fingers. These primary components are secured to the flywheel and transmission input shaft using high-strength Hexagon Head Bolts, ensuring robust power transfer under demanding conditions.
  • Hydraulic/Pneumatic Actuation & Control: Intelligent clutch operation is enabled by the Clutch Booster And Connecting Assembly, which amplifies driver input force, and the Cluth Booster Pump Assembly, providing the necessary hydraulic or pneumatic pressure. Fluid transfer is managed through the Oil Pipe Assembly-Clutch and a series of specialized connectors: Straight Pipe Connectors (appearing multiple times for critical junctions) and the Oil Pipe Joint. Precise mounting of the booster assembly utilizes Threaded Sleeves, Hexagon Nuts, and Spring Washers.
  • Critical Sealing & Fluid Integrity: Maintaining leak-free operation throughout the hydraulic/pneumatic circuit is paramount. This is ensured by multiple sealing solutions: a Seal Ring for general sealing, the Hydraulic and Pneumatic Rubber O-ring for specific fluid compatibility, a Special Shaped Seal Ring for unique sealing challenges, and a Washer, Sealing designed for fluid-tight connections. A Circlip provides essential retention for specific internal components.
  • Secure Mounting & System Management: The entire assembly is meticulously anchored within the vehicle. Large Washers and Spring Washers work in conjunction with Hexagon Nuts and Hexagon Head Bolts to provide vibration-resistant fastening at key points. Routing and protection of flexible components are handled by the Flexible Shaft Fixing Clip With Sheath Assembly and standard Cable Ties, ensuring longevity and preventing interference during operation.
  • This FAW Clutch Logic Assembly exemplifies integrated engineering, combining robust mechanical components, intelligent hydraulic/pneumatic control, fail-safe sealing, and secure mounting hardware to deliver smooth, reliable, and precisely controlled clutch engagement essential for optimal vehicle drivability and powertrain longevity.

Product Parameters of FAW Clutch Logic Assembly

Order Part NO. Part Name And Standards Oty
Clutch Logic Assembly 1
1 CQ1500825 Hexagon Head Bolt 4
2 Q40308 Spring Washer 4
3 1602300-DY889 Clutch Booster And  Connecting Assembly 1
4 1602325-54B Straight  Pipe Connector 2
5 3506408-50A Seal Ring 2
6 3506407-50A Circlip 2
7 3506403-50A Special Shaped Seal Ring 2
8 1602326-54B Straight  Pipe Connector 2
9 CQ734187B Hydraulic and  Pneumatic Rubber O-ring 2
10 3506406-50A Threaded Sleeve 2
11 1602305A70N Cluth Booster Pump Assembly 1
12 1602242A70A Washer, Sealing 1
13 1602241A70A Oil Pipe Joint 1
14 1602325-1500 Straight  Pipe Connector 1
15 CQ34010 Hexagon Nut 12
16 Q40310 Spring Washer 24
17 Q40210 Large Washer 1
18 1602239-Q4603G Flexible Shaft Fixing Clip With Sheath  Assembly 1
19 1602200-DY799 Oil  Pipe Assembly-Clutch 1
20 3506111-DV111 Cable Ties
21 1601310A2001 Clutch Cover Assy 1
22 CQ1501085T Hexagon Head Bolt 12
23 1601430-DY799 Clutch Release Bearing Assy 1
24 1601210A2001 Clutch Driven  Disc Assembly 1
