FAW  Transmission Assembly-Clutch Housing And Related Parts

FAW Transmission Assembly-Clutch Housing And Related Parts
FAW Transmission Assembly-Clutch Housing And Related Parts
Download Catalog
Get Quotation

What is the FAW Transmission Assembly-Clutch Housing And Related Parts

  • Core Transmission Assembly Components
    The FAW Transmission Assembly forms the heart of the powertrain, integrating critical elements for gear shifting and torque transfer. This robust assembly incorporates precision components like the Input Shaft Assy, essential for initial power intake, supported by high-performance Cylindrical Roller Bearings and Deep Slotted Ball Bearings for smooth rotation. Internal sealing integrity is ensured by multiple Seal, O Ring units and specific Seal, Y Ring designs. Key retention features include Stop Rings (used in multiple locations), a Circlip for Shaft, Spring Collar For Hole, and Dowel, Pin for precise alignment. Fastening throughout is handled by numerous Combination Bolt units and Hexagon Head Bolt & Spring Washer Assy sets, securing parts like the End Cover and Gasket.
  • Clutch Housing Assembly & Core Elements
    Central to the clutch operation is the Clutch Housing Assy, providing the structural foundation. Mounted within are vital parts including the Clutch Release Fork Assy for engagement/disengagement and the Clutch Housing Cushion for impact absorption. The housing interfaces with the transmission via the Input Shaft Bearing Cover, sealed by another critical Seal, O Ring and fastened securely with Hexagon Head Bolt & Spring Washer Assy sets. Accessibility and sealing are managed by the Handhole Cover, Operation Window Gasket, and the CA Cup Plug Sheet. Fluid sealing at joints is reinforced with a Washer, Sealing and the Hexagon-headed plug.
  • Hydraulic, Auxiliary & Supporting Parts
    The clutch actuation system relies on the Piston-Eng and associated Seal, O Ring within its hydraulic circuit. Fluid flow is directed through specialized connectors like the 90°Connector and 45°Angle Pipe Joint. The Pump Assembly ensures hydraulic pressure, working in conjunction with the Easy Moving Valve Assy for precise control. The Gland provides necessary sealing for moving parts. Auxiliary functions are supported by the Fork Of Front Auxiliary Gearbox. Filtration is handled by the replaceable Filter Element. Additional structural support comes from the Bent Plate, while Bearing units (general) provide rotational stability. Nut fasteners complement the extensive bolt assemblies, and the Spring Collar For Hole aids specific component location.

Product Parameters of FAW Transmission Assembly-Clutch Housing And Related Parts

Order Part NO. Part Name And Standards Oty
1700045-DY683 Transmission Assembly 1
1 Q1400830 Combination Bolt 4
2 10642002 End Cover 1
3 10642003 Seal, O Ring 1
4 GB890-80-M16X1.5 Nut 1
5 10642006 Seal, Y Ring 2
6 10642001 Piston-Eng 1
7 10642004 Seal, O Ring 1
8 Q43037 Spring Collar For Hole 1
9 10642007 Gasket 1
10 10642005 Seal, O Ring 1
11 Q1401060T Hexagon Head Bolt & Spring Washer  Assy 21
12 JS85T-1701123 Stop Ring 2
13 C01021 Stop Ring 2
14 10641091 Cylindrical  Roller Bearing 2
15 20815 Bent Plate 1
16 Q1401040T Combination Bolt 3
17 12JS160T-1703021 90°Connector 1
18 A-5000-4 Easy Moving Valve Assy 1
19 Q1420640 Combination Bolt 2
20 12880 45°Angle Pipe Joint 1
21 Q1400885T Combination Bolt 8
22 54015 CA Cup Plug Sheet 10
23 10643016 Operation  Window Gasket 1
24 Q1401080 Combination Bolt 2
27 10642014 Bearing 3
28 10642045 Fork Of Front Auxiliary Gearbox 1
29 10721025-1 Input Shaft Assy 1
30 10641075 Dowel, Pin 2
31 10646016 Clutch  Housing Cushion 1
32 Q72320 Washer, Sealing 2
33 Q617B20 Hexagon-headed plug 2
34 10646017 Handhole Cover 1
35 Q1420822 Hexagon Head Bolt & Spring Washer  Assy 4
36 10646010-4 Clutch Housing Assy 1
37 10645017 Filter Element 1
38 10641029 Deep Slotted Ball Bearing 1
39 10641028 Circlip for Shaft 1
40 11845010-1 Pump Assembly 1
11845018 Gland 1
41 Q1401040T Hexagon Head Bolt & Spring Washer  Assy 2
42 10641042 Seal, O Ring 1
43 10641040 Input  Shaft Bearing Cover 1
44 Q1420830 Hexagon Head Bolt & Spring Washer  Assy 6
45 JS180-1601020-136 Clutch Release Fork Assy 1
46 Q1421250 Hexagon Head Bolt & Spring Washer  Assy 2
