Sitrak Front and Rear Suspension Parts Catalog – CHINA TRUCK AND SPARE PARTS SUPPLIER https://deruna.com We are a first-class heavy duty vehicles and spare parts supplier in China. Mon, 07 Apr 2025 11:01:25 +0000 zh-Hans hourly 1 https://deruna.com/wp-content/uploads/2024/05/cropped-deruna-logo-512-32x32.webp Sitrak Front and Rear Suspension Parts Catalog – CHINA TRUCK AND SPARE PARTS SUPPLIER https://deruna.com 32 32 Sitrak T5G8×4 Front Damper (280 Frame, 965 Front And 865 Rear) https://deruna.com/sitrak-t5g8x4-front-damper.html https://deruna.com/sitrak-t5g8x4-front-damper.html#respond Fri, 04 Apr 2025 03:59:19 +0000 https://deruna.com/?p=62129 […]]]>

Sitrak T5G8×4 Front Damper (280 Frame, 965 Front And 865 Rear)

Sitrak T5G8×4 Front Damper (280 Frame, 965 Front And 865 Rear)
Sitrak T5G8×4 Front Damper (280 Frame, 965 Front And 865 Rear)
Download Catalog
Get Quotation

What is the Sitrak T5G8×4 Front Damper (280 Frame, 965 Front And 865 Rear)

  • The Sitrak T5G 8×4 Front Damper (280 Frame, 965 Front And 865 Rear) is a crucial component of the vehicle’s suspension system, designed to enhance ride comfort and stability.
  • The shock absorber upper bracket assembly serves as a key mounting point for the vibration damper. It provides a stable and secure connection between the damper and the vehicle’s frame. This assembly is firmly attached using hexagon head bolts M16*1.5. These bolts are precisely engineered to withstand the forces exerted during vehicle operation, ensuring a reliable connection.
  • The vibration damper itself is the heart of the front damper system. It is responsible for reducing the vibrations and shocks that are transferred from the road surface to the vehicle. By absorbing and dissipating the energy generated by uneven terrain, the damper helps to keep the vehicle’s wheels in contact with the road, improving traction and handling.
  • To secure the vibration damper in place, Type 2 hexagonal nuts M161.5 are used in conjunction with the hexagon head bolts M161.5. These nuts provide a tight and secure fit, preventing any loosening that could compromise the performance of the damper.
  • In addition to the main mounting components, there are also smaller but equally important parts involved. Bolts, along with washers, play a role in the overall assembly. The washers are used to distribute the load evenly and protect the surfaces of the components from damage. Hexagon head bolts M121.25 are used in certain areas of the assembly, and they are paired with Type 2 hexagon nuts M121.25. These smaller fasteners ensure the proper alignment and stability of various sub – components within the front damper system.
  • Overall, the Sitrak T5G 8×4 Front Damper (280 Frame, 965 Front And 865 Rear) with its shock absorber upper bracket assembly, vibration damper, and a variety of fasteners and washers, is a well – engineered system that contributes significantly to the smooth and safe operation of the vehicle.

Product Parameters of Sitrak T5G8×4 Front Damper (280 Frame, 965 Front And 865 Rear)

AC94326800102  T5G8×4 Front Damper (280 Frame, 965 Front And 865 Rear)
No. Part Number Part Name English  Quantity
1 WG9416680001 Shock absorber upper bracket assembly 4
2 ZQ151B16100 Hexagon head bolts M16*1.5 4
3 WG9731681031 Vibration damper 4
4 ZQ361B16 Type 2 hexagonal nut M16*1.5 4
4 ZQ361B16 Type 2 hexagonal nut M16*1.5 4
5 WG9100680036 Bolt 4
6 WG9725680030 Washers 4
7 WG9100680021 Washers 8
8 ZQ151B1240 Hexagon head bolts M12*1.25 16
9 ZQ361B12 Type 2 hexagon nuts M12*1.25 16

Related Sitrak Spare Parts

Didn'T Find Your Truck Model?

If you have any problems or questions, please get in touch with us, we will
provide you with the best service.

Contact Us
]]> https://deruna.com/sitrak-t5g8x4-front-damper.html/feed 0 Sitrak Disconnect Balance Suspension (850, 5 X 37 Less Leaf Springs, Two Riding Bolts, Cast Crossmember, St13/St16 Axle, No Guide Plates) https://deruna.com/sitrak-disconnect-balance-suspension.html https://deruna.com/sitrak-disconnect-balance-suspension.html#respond Fri, 04 Apr 2025 03:55:54 +0000 https://deruna.com/?p=62123

Sitrak Disconnect Balance Suspension (850, 5 X 37 Less Leaf Springs, Two Riding Bolts, Cast Crossmember, St13/St16 Axle, No Guide Plates)

Sitrak Disconnect Balance Suspension (850, 5 X 37 Less Leaf Springs, Two Riding Bolts, Cast Crossmember, St13/St16 Axle, No Guide Plates)
Sitrak Disconnect Balance Suspension (850, 5 X 37 Less Leaf Springs, Two Riding Bolts, Cast Crossmember, St13/St16 Axle, No Guide Plates)
Download Catalog
Get Quotation

What is the Sitrak Disconnect Balance Suspension (850, 5 X 37 Less Leaf Springs, Two Riding Bolts, Cast Crossmember, St13/St16 Axle, No Guide Plates)

  • The Sitrak Disconnect Balance Suspension (850, 5 X 37 Less Leaf Springs, Two Riding Bolts, Cast Crossmember, St13/St16 Axle, No Guide Plates) is a high – performance suspension system with a variety of essential components.
  • The balance shaft with housing assembly forms the core of the suspension, ensuring smooth operation and proper weight distribution. The cast thrust rod assembly provides strong support and stability, while the low leaf rear plate spring assemblies offer reliable shock absorption. The V – Thrust Rod Assembly helps in maintaining the correct alignment of the axles.
  • There are multiple types of fasteners and nuts used in this suspension. The Type 2 hexagonal nut M221.5, Type 2 all – metal hexagonal lock nuts, Type 2 hexagon nuts M201.5, Type 1 hexagonal nut M101.5, and Type 2 hexagonal nut M141.5 are all crucial for securely holding different parts together. Bolts such as hexagon head bolts M221.5, hexagon head bolts M201.5, hexagon head bolts M141.5, and hexagon head bolts M8 are used throughout the assembly. Hexagonal flange face bolts with teeth M161.5 and hexagonal flange bolts with teeth M8 provide enhanced grip and prevent loosening.
  • The clamp plate is used to hold components firmly in place. The rubber bearing assembly reduces vibration and noise. The thrust rod front left bracket is an important structural part for the thrust rod.
  • The limit bracket and limit block assembly are designed to prevent excessive movement and protect the suspension components. The plate spring pressure plate helps in compressing the leaf springs effectively. Rear spring jockey bolts are used to adjust and secure the rear springs.
  • Other components like flat washers, heavy – duty spring washers, sealing washers, sealing rings, positioning washers, and locating washers are used for proper alignment, sealing, and protection. The shell cover, bearing oil seal cover, and balance shaft housing enclose and protect internal components. Spacer bushings, bearing presses, and spherical bearings ensure smooth rotation and proper functioning of the balance shaft.
  • The V type thrust rod bolts, anti – loosening sleeve, hexagonal flange nuts M181.5, and double head studs are all integral parts of the suspension system. Additionally, hexagon socket plugs with tapered thread are used for sealing and protection, and the bracket provides support for various components. Cylindrical pins, such as Pin GB119 A2024, are used for precise positioning. Shaft seals prevent leakage of lubricants and keep the internal parts clean. All these components work together to make the Sitrak Disconnect Balance Suspension a reliable and efficient system.

Product Parameters of Sitrak Disconnect Balance Suspension (850, 5 X 37 Less Leaf Springs, Two Riding Bolts, Cast Crossmember, St13/St16 Axle, No Guide Plates)

AC97255209925  Disconnect Balance Suspension (850, 5 X 37 Less Leaf Springs, Two Riding Bolts, Cast Crossmember, St13/St16 Axle, No Guide Plates)
No. Part Number Part Name English  Quantity
1 AZ9725520210 Balance shaft with housing assembly 2
2 AZ9631523175 Cast Thrust Rod Assembly 4
3 WG9725521282 Low Leaf Rear Plate Spring Assemblies 2
4 AZ9725529272 V-Thrust Rod Assembly 2
5 WG9725520266 Clamp plate 4
6 ZQ361B22T13F6 Type 2 hexagonal nut M22*1.5 16
7 AZ9725520273 Rubber Bearing Assembly 4
8 ZQ151B22250TF6 Hexagon head bolt M22*1.5 16
9 WG9725520590 Thrust rod front left bracket 4
10 Q33212 Type 2 all-metal hexagonal lock nuts 16
11 Q218B1285 Hexagon socket cheese head screws 16
12 WG9725520267 Casing 16
13 WG9725520265 Fixing strip 8
14 ZQ151B20100TF6 Hexagon head bolts M20*1.5 8
15 190003901905 Cylindrical pins–Pin GB119 A20*24 4
16 ZQ361B20T13F6 Type 2 hexagon nuts M20*1.5 12
17 ZQ151B20180TF6 Hexagon head bolts M20*1.5 4
18 ZQ1811670TF6 Hexagonal flange face bolts with teeth M16*1.5 2
19 WG9725520736 Limit bracket 4
20 WG9725520727 Limit block assembly 4
21 ZQ151B1470 Hexagon head bolts M14*1.5 12
22 ZQ151B1460 Hexagon head bolts M14*1.5 4
23 ZQ340B10 Type 1 hexagonal nut M10*1.5 16
24 ZQ361B14 Type 2 hexagonal nut M14*1.5 16
25 WG9725520256 Plate spring pressure plate 2
26 ZQ32724T13F3 Flange nuts M24*3 8
27 AZ9725521265 Rear spring jockey bolts 4
28 ZQ1811660TF6 Hexagonal flange bolts with teeth M16*1.5 28
29 ZQ1811690TF6 Hexagonal flange bolts with teeth M16*1.5 8
30 Q40120 Flat washers 4
31 ZQ151B20120 Hexagon head bolts M20*1.5 4
33 ZQ32516T13F6 Hexagonal flange nuts with teeth M16*1.5 38
33 ZQ32516T13F6 Hexagonal flange nuts with teeth M16*1.5 16
34 ZQ1811680TF6 Hexagonal flange face bolts with teeth M16*1.5 16
35 WG9725520114 V type thrust rod bolts 8
36 WG9725520367 Anti-loosening sleeve 8
37 ZQ32318T13F6 Hexagonal flange nuts M18*1.5 8
38 WG9725520231 Double head studs 8
AZ9725520210 Balance shaft with housing assembly
No. Part Number Part Name English  Quantity
1 190003962021 Hexagon socket plugs with tapered thread 1
2 AZ9725520233 Bracket 1
3 AZ9725520237 Balance shaft 1
4 ZQ1800820TF6 Hexagonal flange bolts with teeth M8 8
5 Q151B1655TF2 Hexagon head bolts(fine thread) 6
7 Q40516 Heavy duty spring washers 6
8 Q5211630 Cylindrical pins 1
9 Q72308T5F Sealing washers 1
10 WG614 130062 Sealing ring 1
11 WG9014520192 Positioning washers 1
12 WG9014520193 Locating Washers 1
13 WG9014520194 Locating washers 1
14 WG9014520303 Positioning washers 1
15 WG9014520306 Positioning washers 1
16 WG9014520311 Shell cover 1
17 WG9100520008 Locating washers 1
18 WG9114520042 Spherical bearings 2
19 WG9114520059 Locating washers 1
20 WG9114520223 Shaft seals 1
21 WG9725520136 Bearing oil seal cover 1
22 WG9725520235 Balance shaft housing 1
23 WG9725520238 Spacer Bushings 1
24 WG9725520239 Bearing presses 1
25 WG9925520223 Shaft seals 1
26 ZQ150B0812 Hexagon head bolts M8 1


Related Sitrak Spare Parts

Didn'T Find Your Truck Model?

If you have any problems or questions, please get in touch with us, we will
provide you with the best service.

Contact Us
]]> https://deruna.com/sitrak-disconnect-balance-suspension.html/feed 0 Sitrak C5H Double Front Axle Suspension(Front 965 Rear 850,880 Leaf Spring Distance,42090 Less Leaf Spring,108 Clamping Distance,No Steering Device Shock Absorber,Mixer Truck) https://deruna.com/sitrak-c5h-double-front-axle-suspension.html https://deruna.com/sitrak-c5h-double-front-axle-suspension.html#respond Fri, 04 Apr 2025 03:51:00 +0000 https://deruna.com/?p=62117

Sitrak C5H Double Front Axle Suspension(Front 965 Rear 850,880 Leaf Spring Distance,42090 Less Leaf Spring,108 Clamping Distance,No Steering Device Shock Absorber,Mixer Truck)

Sitrak C5H Double Front Axle Suspension(Front 965 Rear 850,880 Leaf Spring Distance,42090 Less Leaf Spring,108 Clamping Distance,No Steering Device Shock Absorber,Mixer Truck)
Sitrak C5H Double Front Axle Suspension(Front 965 Rear 850,880 Leaf Spring Distance,42090 Less Leaf Spring,108 Clamping Distance,No Steering Device Shock Absorber,Mixer Truck)
Download Catalog
Get Quotation

What is the Sitrak C5H Double Front Axle Suspension(Front 965 Rear 850,880 Leaf Spring Distance,42090 Less Leaf Spring,108 Clamping Distance,No Steering Device Shock Absorber,Mixer Truck)

  • The Sitrak C5H Double Front Axle Suspension, specifically designed for mixer trucks, is a crucial component that ensures optimal performance and stability. This suspension system features a front 965 and rear 850,880 leaf spring distance, with 42090 less leaf spring and a 108 clamping distance. It is also characterized by the absence of a steering device shock absorber, which is tailored to meet the specific requirements of mixer trucks.
  • Key Components
  • Front Leaf Spring Assemblies
  • The front leaf spring assemblies are the heart of the suspension system. They are responsible for supporting the weight of the vehicle and absorbing shocks from the road surface. These assemblies are carefully engineered to provide the right balance of flexibility and strength.
  • Spring Seat
  • The spring seat serves as the foundation for the leaf springs. It provides a stable and secure mounting point, ensuring that the leaf springs function effectively.
  • Front Spring Riding Bolt
  • The front spring riding bolt plays a vital role in holding the leaf springs in place. It ensures that the springs are properly aligned and can withstand the forces exerted during vehicle operation.
  • Left and Right Front Spring Levers
  • The left and right front spring levers are designed to transfer the forces from the leaf springs to the vehicle’s frame. They help in maintaining the stability and balance of the suspension system.
  • Front Spring Lugs
  • The front spring lugs are used to connect the leaf springs to the front spring brackets. They provide a flexible connection that allows for movement and adjustment.
  • Front Spring Rear Bracket (Standard Hole) and Front Spring Front Bracket (Standard Hole)
  • These brackets are essential for mounting the leaf springs. The standard holes ensure a precise fit, making installation easier and more reliable.
  • Front Spring Front Bracket
  • The front spring front bracket further enhances the support and stability of the leaf springs. It is designed to withstand the high loads and stresses associated with vehicle operation.
  • Reinforcement Plate Assembly
  • The reinforcement plate assembly adds additional strength to the suspension system. It helps in distributing the loads evenly and preventing damage to the components.
  • Limit Block Bracket and Limit Block Bracket (850 Frame 880 Leaf Spring Pitch)
  • The limit block brackets are used to limit the movement of the leaf springs. They ensure that the springs do not overextend or cause damage to other components.
  • Limit Block Assembly
  • The limit block assembly works in conjunction with the limit block brackets to provide a safe and controlled range of movement for the leaf springs.
  • Fasteners and Other Components
  • The suspension system also includes a variety of fasteners such as hexagon head bolts (M121.25, M141.5), type 2 hexagonal nuts (M121.25, M141.5), grease nipple assembly (CM101 D71412), spring pins, flange nut (M202.5), guide pin, hexagonal flange face bolts with teeth (M141.5), hexagonal flange bolts with teeth (M141.5), hexagonal flange nuts with teeth (M14*1.5), and washers. These components are essential for ensuring the proper assembly and functioning of the suspension system.
  • In conclusion, the Sitrak C5H Double Front Axle Suspension for mixer trucks is a well – designed and reliable system. Its carefully selected components work together to provide excellent performance, stability, and durability, making it an ideal choice for mixer truck applications.

Product Parameters of Sitrak C5H Double Front Axle Suspension(Front 965 Rear 850,880 Leaf Spring Distance,42090 Less Leaf Spring,108 Clamping Distance,No Steering Device Shock Absorber,Mixer Truck)

AC94255206236  C5H Double Front Axle Suspension(Front 965 Rear 850,880 Leaf Spring Distance,42090 Less Leaf Spring,108 Clamping Distance,No Steering Device Shock Absorber,Mixer Truck)
No. Part Number Part Name English  Quantity
1 WG9731522006 Front Leaf Spring Assemblies 4
2 WG9719520070 Spring Seat 4
3 AZ9925520230 Front Spring Riding Bolt 8
4 WG9416520111 Left Front Spring Lever 2
5 WG9416520112 Right Front Spring Lever 2
6 WG9416520007 Front Spring Lugs 4
7 WG9416520055 Front Spring Rear Bracket(Standard Hole) 4
8 WG9416520053 Front Spring Front Bracket(Standard Hole) 2
9 WG9425520003 Front Spring Front Bracket 2
10 WG9425520009 Reinforcement Plate Assembly 2
11 WG9416520014 Limit Block Bracket 2
12 WG9731520208 Limit Block Bracket (850 Frame 880 Leaf Spring Pitch) 2
13 WG9416520030 Limit block assembly 4
14 ZQ151B1235 Hexagon head bolt M12*1.25 4
15 ZQ361B14 Type 2 hexagonal nut M14*1.5 6
16 ZQ151B1455 Hexagon head bolt M14*1.5 6
18 ZQ151B1285 Hexagon head bolts M12*1.25 4
19 ZQ361B12 Hexagon nuts type 2 M12*1.25 4
19 ZQ361B12 Hexagon nuts type 2 M12*1.25 4
20 ZQ361B14T13F6 Hexagon nuts type 2 M14*1.5 8
21 ZQ151B1450TF6 Hexagon head bolts M14*1.5 8
22 ZQ151B1270TF6 Hexagon head bolts M12*1.25 12
23 ZQ361B12T13F6 Hexagon nuts type 2 M12*1.25 12
24 AZ9003963022 Grease nipple assembly (CM10*1 D71412) 12
25 WG9100520065 Spring pin 2
27 ZQ32720T13F3 Flange nut M20*2.5 16
28 WG9100520665 Spring pin 10
29 WG9000520006 Guide pin 4
30 ZQ1811445TF6 Hexagonal flange face bolts with teeth M14*1.5 10
30 ZQ1811445TF6 Hexagonal flange bolts with teeth M14*1.5 20
31 ZQ32514T13F6 Hexagonal flange nuts with teeth M14*1.5 10
31 ZQ32514T13F6 Hexagonal flange nuts with teeth M14*1.5 20
32 WG1680520050 Washers 24
WG9731522006 Leaf less front leaf spring assembly
No. Part Number Part Name English  Quantity
1 WG9731522006/1 Front Plate Spring Assembly (Jinan Fangda Heavy Duty) 1
WG9731522006/1 Less leaf front steel plate spring assembly (Jinan Fangda Heavy Duty)
No. Part Number Part Name English  Quantity
1 WG9731522006+001/1 Front steel plate spring assembly(thickness 20mm,Fonda) Part 1 1
2 WG9731522006+002/1 Front Leaf Spring Assembly(20mm Thickness,Fonda) Part 2 1
3 WG9731522006+003/1 Front Leaf Spring Assembly (20mm Thickness, Fonda Heavy Duty) 3rd Piece 1
4 WG9731522006+004/1 Front leaf spring assembly (thickness 20mm, Fonda) 4th piece 1
5 WG9731522006+005/1 Center bolt (Founder) 1
6 WG9731522006+006/1 Center Nut(Fonda) 1
AZ9003963022 Grease nipple assembly (CM10*1 D71412)
No. Part Number Part Name English  Quantity
1 AZ9003963010 Grease Nipple Cap 1
2 190003963127 Metric tapered thread grease nipple 1
