What is the FAW Front Axle Assembly -Brake Assembly

  • 1. FAW Front Axle Brake Assembly: Heavy-Duty Stopping Power
    Integrated within the FAW Front Axle Assembly, the robust Front Left Brake Assembly and Front Right Brake Assembly deliver reliable, high-torque drum braking for FAW commercial trucks. This S-cam system is engineered for consistent performance under extreme loads and frequent use.
  • 2. Structural Foundation & Actuation Mounting
  • Anchor Points: The Front LH Brake Bracket & Cam Bracket Assembly and Front RH Brake Bracket & Cam Bracket Assembly provide rigid mounting to the axle, precisely locating the Front Brake Shoe Facing Shaft (anchor pin) and Front Left Cam Shaft / Front Right Cam Shaft.
  • Camshaft Support: Washer-Brake Cam Shaft and Grease Nozzle ensure smooth cam rotation and maintenance access. Bolt, Spring Washer, and Plain Washer combinations secure brackets.
  • 3. Brake Shoe & Friction System
  • Primary & Secondary Shoes:
  • Front LH Upper (RH Lower) Brake Shoe Facing With Friction Block Assy (typically leading/trailing shoe)
  • Front LH Lower (RH Upper) Brake Shoe Facing With Friction Block Assy
    (Note: LH Upper acts as RH Lower due to mirrored assembly).
  • Force Application: Shoes pivot on the Front Brake Shoe Facing Shaft and are forced outward against the drum by the rotating S-cams.
  • Retraction: Retracting Spring-Front Brake Shoe Facing actively pulls shoes away post-braking, preventing drag.
  • 4. Dust Protection & Sealing
  • Critical Shields: Front Brake LH Upper (RH Lower) Dust-Proof Pan and Front Brake LH Lower (RH Upper) Dust-Proof Pan enclose each assembly, shielding internal components from road debris and moisture.
  • Access & Sealing: Plug -Check Hole Of Dust-Proof Pan allows inspection/cleaning. Gasket-Brake Adjusting Arm seals the adjuster interface.
  • 5. Slack Adjustment Mechanism
  • Automatic Adjustment: The Front Left Brake Adjusting Arm Assy and Front Right Brake Adjusting Arm Assy automatically compensate for brake lining wear, maintaining optimal shoe-to-drum clearance.
  • Adjuster Hardware: Utilizes Brake Adjusting Washer, secured by Bolt, Spring Washer, Plain Washer, Split Pin, and Flat Pin for safety-critical retention.
  • 6. Brake Chamber & Final Activation
  • Air Pressure Conversion: The Front Brake Chamber Assy converts air pressure into mechanical force, rotating the S-cam shaft via a pushrod and slack adjuster linkage.
  • Linkage Mounting: Connected via Bracket and secured with Bolt, Spring Washer, and Plain Washer.

Product Parameters of FAW Front Axle Assembly -Brake Assembly

Order Part NO. Part Name And Standards Oty
3000010G1705 Front  Axle Assembly 1
3501015A901/AL01 Front Left Brake Assembly 1
3501020A901/AL01 Front Right Brake Assembly 1
1 3501025C242 Front LH Brake Bracket  & Cam Bracket Assembly 1
1 3501030C242 Front RH Brake Bracket  & Cam Bracket Assembly 1
2 3501082-4E Front Brake Shoe Facing Shaft 2
3 3501151C242 Front Left Cam Shaft 1
3 3501152C242 Front Right Cam Shaft 1
4 CQ70001 Grease Nozzle 1
5 Q43138 Plain Washer 1
6 3501251-A0S Gasket-Brake  Adjusting Arm 1
7 3501205D242-C00 Front Left Brake Adjusting Arm  Assy 1
7 3501210D242-C00 Front Right Brake Adjusting Arm  Assy 1
8 CQ1500816 Bolt 1
9 Q40308 Spring Washer 1
10 Q40108 Plain Washer 1
11 Q40108 Plain Washer 1
12 3501033-242 Bracket 1
13 CQ1500620 Bolt 2
14 Q40306 Spring Washer 2
15 3501156A392 Brake  Adjusting Washer 2
16 CQ1500610 Bolt 8
17 Q40306 Spring Washer 8
18 3501380C242 Front LH Lower (RH Upper)Brake Shoe Facing With Friction Block Assy 1
18 3501375C242 Front LH Upper (RH Lower)Brake Shoe  Facing 1
19 3501032-4E With Friction Block Assy
19 3501031-4E Front Brake LH Lower (RH Upper)  Dust-Proof 1
20 3501031-4E Front Brake LH Upper (RH Lower) Dust-Proof  Pan 1
20 3501032-4E Front Brake LH Upper (RH Lower) Dust-Proof  Pan 1
21 3501087-4E Front Brake LH Lower (RH Upper) Dust-Proof  Pan 1
22 CQ1501016 Bolt 1
23 3501086-4E Baffle 1
24 3501375C242 Front LH Upper (RH Lower)Brake Shoe  Facing 1
24 3501380C242 With Friction Block Assy
25 3519110-95A Front LH Lower (RH Upper)Brake Shoe  Facing 1
26 3501436-4E With Friction Block Assy
27 3501153-A0S Front Brake Chamber Assy 1
28 3501034-02 Retracting Spring-Front Brake Shoe  Facing 1
29 Q5003025 Washer-Brake  Cam Shaft 1
30 Q40114 Plug -Check Hole Of Dust-Proof  Pan 2
31 Q5101438 Split Pin 1
42 10641042 Plain Washer 1
43 10641040 Flat Pin 1
