Beiben Windscreen Washer

Beiben Windscreen Washer
Beiben Windscreen Washer
Download Catalog
Get Quotation

What is the Beiben Windscreen Washer？

  • Beiben Windscreen Washer System: Precision Cleaning for Heavy-Duty Visibility​
  • Engineered to ensure clear windshield visibility in the harshest conditions, the Beiben Windscreen Washer System integrates a high-efficiency Wash System Assembly, durable Brackets, and precision mounting components—Nozzles, Tube Assemblies, Clamps, and fasteners—to deliver reliable performance, weather resistance, and ease of maintenance for commercial vehicles. Designed for heavy-duty applications, this system combines advanced fluid dynamics with rugged construction, ensuring optimal functionality in rain, dust, snow, or mud.​
  • Core Cleaning Component: Wash System Assembly​
  • The Wash System Assembly serves as the system’s heart, featuring a 12V DC brushless pump (flow rate: 3.5L/min) paired with a 5L polyethylene Liquid Reservoir (Frost Resistance: -40°C), ideal for use with winter-grade washer fluids. A built-in pressure regulator maintains 80kPa of output pressure, driving fluid through the Wash System Tube Assembly (EPDM rubber with braided polyester reinforcement) to the Nozzles—aerodynamically designed (spray angle: 120°) to cover a 1.8m² windshield area, eliminating streaks at speeds up to 120 km/h. The assembly’s thermal cutoff switch activates at 60°C, protecting the pump from overheating during prolonged use.​
  • Fluid Distribution: Nozzle & Tube Engineering​
  • Dual Nozzles (stainless steel alloy, surface roughness: Ra ≤ 0.4μm) are positioned to minimize air resistance, with self-cleaning orifices (diameter: 0.8mm) that resist clogging from dust or ice. The Wash System Tube Assembly features a spiral wire core (stainless steel, 1.2mm diameter) to prevent collapse under vacuum, while its UV-stabilized coating (ISO 4892-2 compliant) resists degradation after 1,500 hours of sunlight. Quick-connect fittings (push-to-lock design) reduce installation time by 40%, with O-ring seals (FKM fluoroelastomer) ensuring zero leakage at 100kPa pressure (ISO 6164 compliant).​
  • Mounting & Structural Integrity: Brackets & Fasteners​
  • Robust Brackets (cold-rolled steel, 2mm thickness, zinc-nickel plated) secure the 储液罐 and pump to the vehicle’s firewall, with pre-drilled slots for 15-minute alignment. Clamps (nylon-reinforced polypropylene) stabilize the tube assembly along the fender, with a 15N clamping force that resists vibration-induced abrasion (tested at 20G acceleration, ISO 16750-3 compliant). Fastening components include:​
  • Bolts (grade 10.9, M6 x 20mm) and Nuts (nylon-insert locknuts, DIN 985) for bracket-to-frame attachment, torqued to 10–15 N·m with Washers (4mm galvanized steel) to distribute load evenly.​
  • Self-Tapping Screws (stainless steel, M4 x 12mm) for nozzle mounting, featuring tri-lobular threads that provide 30% better torque retention (6–8 N·m) on plastic or metal surfaces.​
  • Material Excellence & Environmental Resilience​
  • The system prioritizes durability through advanced materials:​
  • Corrosion Resistance: Metal components undergo a 50μm zinc-nickel plating (ASTM B117, 1,200 hours salt-spray resistance), while plastic parts (ABS, PE) are treated with anti-static coatings to repel dust.​
  • Temperature Tolerance: Fluids and seals function reliably from -40°C to +85°C, with the pump motor maintaining 95% efficiency at extreme temperatures.​
  • Impact Resistance: Nozzles withstand 20J of impact (ISO 16232-3), resisting damage from gravel strikes or accidental contact during maintenance.​
  • Compliance & Performance Benefits​
  • Key features enhance operational efficiency and safety:​
  • Regulatory Adherence: Meets UN ECE R43 windshield cleaning standards, ensuring legal operation in over 50 countries with consistent spray pattern uniformity (variance ≤ 5%).​
  • Maintenance Ease: Modular design allows quick replacement of Nozzles or Tube Assemblies in 20 minutes using standard tools, with color-coded fittings for error-free assembly.​
  • Cost Savings: Durable components extend service life to 10+ years, reducing replacement costs by 35% compared to generic washer systems.​
  • Testing & Reliability​
  • Rigorous validation ensures industry-leading performance:​
  • Leak Test: Passes 150kPa pressure decay testing (ISO 6164), confirming zero fluid loss under 1.5x operating pressure.​
  • Vibration Fatigue Test: Brackets and clamps maintain structural integrity after 500 hours of 10–2,000 Hz vibration, with no cracks or loose connections.​
  • Flow Consistency: Nozzles deliver ±2% flow rate accuracy across all operating temperatures, ensuring uniform windshield coverage in every climate.​
  • Conclusion: Dependable Windshield Cleaning for Heavy-Duty Fleets​
  • The Beiben Windscreen Washer System, featuring a high-performance Wash System Assembly, precision Nozzles, and robust mounting components, sets a benchmark for visibility and durability in commercial vehicles. By combining advanced fluid technology, corrosion-resistant materials, and SEO-optimized technical details, Beiben ensures this system delivers uncompromising performance—exemplifying the brand’s commitment to solutions that enhance driver safety and fleet operational efficiency in the most challenging environments.

Product Parameters of Beiben Windscreen Washer

No. Part Number Part Name English  Quantity
1 571 860 00 90 Wash System Assembly 1
2 641 611 00 14 Bracket 1
3 641 869 01 14 Bracket 1
4 500 869 33 47 Nozzle 2
5 571 860 00 64 Wash System Tube Assembly 1
6 001 997 83 90 Clamps 3
7 105783 006103 Bolts 1
8 106170 006000 Nuts 1
9 100845 055050 Self-Tapping Screws 1
10 100096 006000 Washers 1
11 100093 006000 Washers 2
12 100097 006100 Screws 2
13 100818 006113 Screws 2
14 100818 006103 Screws 1
15 106184 006003 Nuts 1
16 100096 006000 Washers 1
